Wiring & Electrical Connections; Connect The Smartrax Hydraulic Valve - Raven SmarTrax Installation Manual

CHAPTER
5

Connect the SmarTrax Hydraulic Valve

Place a solenoid gasket (included in the packet with the console cable harness) on the solenoid installed in
1.
port '1A' on the SmarTrax hydraulic valve (P/N 334-0003-066).
Locate the connector labeled 'LEFT' on the SmarTrax console cable harness (P/N 115-0171-775).
2.
Insert the connector labeled 'LEFT' to the solenoid installed in port '1A' on the SmarTrax hydraulic valve.
3.
Tighten the screw on the connector to secure the solenoid connection.
4.
Repeat step 1 through step 4 to connect the 'RIGHT' connector to the solenoid on port '1B.'
5.
Manual No. 016-0190-085
W iring & Electrical
C h a p t e r 5
Connections
CAUTION
Ensure that the power cable is the last cable
connected and the leads are connected to the
correct polarity.
Do not reverse the power leads. Doing so will
cause severe damage to the equipment.
