QUATTROCODE
5

DECODING KEYS

WARNING: to install the key in the clamp, see Ch. 'Appendix 1 - Clamps'.
5.1

Decoding

WARNING: the J1 (standard) clamp is used as a model for the description of clamp decoding
operations. If using other clamps, enter the code for the clamp installed and use the same
sequence.
To carry out decoding operations, work from the PC and then the machine, according to the
following instructions.
O
PERATIONS ON THE
1) Open the search menu.
2) Select the <SEARCH> function.
3) Enter the name of the system/lock.
4) Press <F10> to display further information on the system/lock selected.
5) Select the item 'Key decoding' from the main menu.
When ENTER is pressed the computer transfers the data to the key-cutting machine (make sure
that the machine is on and connected to the PC).
O
PERATIONS ON THE MACHINE
Press
START
Press
START
Raise the protective shield and place the key all the way into the clamp (fig. 19, page 21).
Press
START
Raise the protective shield and place the decoder in position (as per chap. 19, page 21). Lower
the protective shield.
Press
START
The results of the decoding operations will appear on the PC video screen.
PC
<DECODE...>
<J1 - A
ST = 0>
<INSTALL
DECOD U...>
and begin the decoding operation; the display will show:
<DECODE (....)>
