QUATTROCODE
7.4

Display and keypad test

Test 401: Display
On receiving instructions from the PC all the illuminated segments will light up in turn (fig. 24).
The test ends when all segments are illuminated and is then automatically repeated.
Fig. 24
If any of the segments fail to light up, contact Silca After-Sales Service.
The display test can be interrupted by running another test from the PC or by pressing the TEST
key on the keypad.
Test 402: Keypad
- Number of test on the display:
Pressing any key (except the TEST key which disactivates the test function) should cause the
symbol on the key to appear on the display.
EXAMPLE:
When the
If any of the keys fail to respond or if the symbol displayed does not correspond to that on the key,
contact Silca After-Sales Service.
key is pressed the display will show:
START
Copyright Silca 1999
<TEST 402>
<START>
Operating manual - English
33
