Silca Quattrocode Operating Manual page 24

Operating manual - English
Press
START
Take the decoder from its housing (fig. 12, page 17).
If the decoder is taken from its housing and is not recognized by the machine when fitted into the
spindle, the following message appears:
The machine will go through the setting up operations only if there is a decoder in the spindle.
Proceed as described in the chapter 'Replacing the cutting tool'.
Press
START
The machine will set itself up. If the spindle is open and the decoder has not been fitted, the
following message appears:
If the spindle is locked without the cutting tool in it, the machine starts, only to stop when it reaches
the safety measurement stops.
When set-up has been carried out the PC screen shows the OFFSET data (i.e. the variation from
"theoretical zero", expressed in hundredths of millimetres) for the X, Y and Z axes.
24
<INSTALL DECODER U101>
<DECODER MISSING>
<DECODER MISSING>
Copyright Silca 1999
QUATTROCODE
