KNOWING YOUR DESIGN ESPRESSO MACHINE BASIC

1 HEATED WARMING PLATE for pre-heating and keeping
warm heat-resistant cups and glasses.
2 TEMPERATURE GAUGE - Use this measuring device for
checking the correct temperature.
3 STEAM BUTTON - Pressing this button toggles to the steam
function (button stays pressed).
4 ESPRESSO BUTTON - Press here for extracting espresso or
getting hot water (button stays pressed).
5 POWER BUTTON - For switching the espresso machine on
and off.
6 STEAM DIAL - Turn this dial for selecting the hot water flow or
controlling the steam function.
7 ESPRESSO INDICATOR (GREEN) - The correct extraction
temperature is reached, when this indicator illuminates.
EN
66
2
3
4
5
7
8
9
11
1
6
10
13
8 POWER INDICATOR (RED) - Illuminated, when the machi-
ne is switched on.
9 STEAM INDICATOR (YELLOW) - Illuminates, when the
water system is ready for giving off steam.
10 GROUP HEAD INCLUDING THE OPERATING ELEMENTS
Install the portafilter at the group head for extracting espresso.
11 STAINLESS STEEL PORTAFILTER WITH 2 SPOUTS
12 180° SWIVEL STEAM WAND
13 REMOVABLE DRIP TRAY
filling indicator
12
with metal cup tray and red
.
