Adapter FRU number
01FT704
I/O bus architecture
PCIe3 x16.
Slot requirement
For details about slot priorities, maximums, and placement rules, see PCIe adapter placement rules
and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER9/p9eab/
p9eab_mtm_pciplacement.htm) and select the system you are working on..
Voltage
3.3 V, 12 V.
Form factor
Short, low-profile.
Maximum number
For details about the maximum number of adapters that are supported, see PCIe adapter placement
rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER9/p9eab/
p9eab_mtm_pciplacement.htm) and select the system you are working on..
Attributes provided
32 Gb/s of throughput.
Enhanced diagnostics and manageability.
Unparalleled performance and more efficient port usage.
Single initiator capability over a fiber link or with NPIV.
Multiple initiator capabilities.
Operating system or partition requirements
If you are installing a new feature, ensure that you have the software that is required to support the new
feature and that you determine whether any prerequisites must be met for this feature and attaching
devices. For information about operating system and partition requirements, see one of the following
topics:
• The latest version of enabling libraries and utilities can be downloaded from Fix Central (http://
www.ibm.com/support/fixcentral/).
• Power Systems Prerequisites (http://www14.software.ibm.com/support/customercare/iprt/home).
• IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/
ssic/interoperability.wss).
• The latest version of the device driver or IBM Power RAID adapter utilities (iprutils) can be downloaded
from the IBM Service and Productivity Tools website (http://www14.software.ibm.com/webapp/
set2/sas/f/lopdiags/home.html).
• For support details, see the Linux Alert website (http://www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.html).
PCIe3 x8 4-port Fibre Channel (16 Gb/s); (FC EL5W, EL5X, EN1C, and EN1D; CCIN 578E)
Learn about the specifications and operating system requirements for feature code (FCs) EL5W, EL5X,
EN1C, and EN1D (EL5X) adapters.
Overview
The FC EN1C (EL5W) and EN1D (EL5X) are electronically identical. FC EN1C (EL5W) is a full-height
adapter and FC EN1D (EL5X) is a low-profile adapter.
The PCIe3 x8 4-port fibre Channel (16 Gb/s) Adapter is a PCI Express (PCIe) generation 3 (Gen3) x8
adapter. The adapter can be used in either a x8 or x16 PCIe slot in the system. This adapter is a high-
performance is based on the Broadcom LPe31004-series PCIe host bus adapter (HBA). The adapter
provides four ports of 16 Gb Fibre Channel capability that uses SR optics. Each port can provide up to 16
