Transceivers
IBM qualifies and supports QSFP28 optical transceiver (FC EB59) to install into the adapter.
Customers can also use their own optical cabling and QSP28 optical transceiver for the other end.
This is a 100Gbase-SR4 based active optical transceiver capable up to 100 M through the OM4 cable
or 70 M through OM3 cable. Either one or both of the adapter's two QSP28 ports can be populated.
When two ports are filled, both can have copper cables or optical cables. Additionally, one of the
cables can be copper and the other can be optical. IBM
EB27) to install into the adapter and allowing the customer to use their own optical cabling and QSFP
+ optical transceiver for the other end.
Cable and transceiver matrix
Table 15. Cable and transceiver matrix
Feature
EB59
EB5J
EB5K
EB5L
EB5M
EB5R
EB5S
EB5T
EB5U
EB5V
EB5W
EB5X
EB5Y
EB2B
EB2H
EB27
Voltage
3.3 V, 12 V
54 Power Systems: Installing the System and Ordered Parts for the IBM Power System IC922 (9183-22X)
®
also offers QSFP+ optical transceiver (FC
Description
100Gbase-SR4 optical transceiver MTP/MPO
cable (purchased separately)
• FC EB2J - 10 M
• FC EB2K - 30 M
QSFP28 Passive Copper 100 Gb Ethernet Cable
- .5 M
QSFP28 Passive Copper 100 Gb Ethernet Cable -
1 M
QSFP28 Passive Copper 100 Gb Ethernet Cable -
1.5 M
QSFP28 Passive Copper 100 Gb Ethernet Cable -
2 M
QSFP28 AOC 100 Gb Ethernet Cable - 3 M
QSFP28 AOC 100 Gb Ethernet Cable - 5 M
QSFP28 AOC 100 Gb Ethernet Cable - 10 M
QSFP28 AOC 100 Gb Ethernet Cable - 15 M
QSFP28 AOC 100 Gb Ethernet Cable - 20 M
QSFP28 AOC 100 Gb Ethernet Cable - 30 M
QSFP28 AOC 100 Gb Ethernet Cable - 50 M
QSFP28 AOC 100 Gb Ethernet Cable - 100 M
1 M Passive QSFP+ to QSFP+
3 M Passive QSFP+ to QSFP+
QSFP+ 40G BASE-SR4 optical transceiver
MTP/MPO cable (purchased separately)
• FC EB2J - 10 M
• FC EB2K - 30 M
