Dmx Chart - Event Lighting PAR6X12OB User Manual

Select intensity of static
colour (R255+G50)
Select intensity of static
colour (G255)
Select intensity of static
colour (G160+B255+UV100)
Select intensity of static
colour (B255+UV50)
Select intensity of static
colour (R50+B255+UV200)
Select intensity of static
colour (R255+B150+UV255)
Select intensity of static
colour (R255+B20+A200)
Reset factory default setting
No function
Add strobe effect on CC, CP,
SU, dE, dl and static colour
mode.

DMX Chart

6 Channel Mode
Channel
1
2
3
4
5
6
10 Channel Mode
www.event-lighting.com.au
Value
000-255 Red: 0% ~ 100%
000-255 Green: 0% ~ 100%
000-255 Blue: 0% ~ 100%
000-255 White: 0% ~ 100%
000-255 Amber: 0% ~ 100%
000-255 UV: 0% ~ 100%
to
to
to
to
to
to
to
to
No change
Function
7
Use to change intensity
Use to change intensity
Use to change intensity
Use to change intensity
Use to change intensity
Use to change intensity
Use to change intensity
Press <STROBE> button to cycle
though 1/8 change of strobe speed
