RS 485 Communication(option)
Modbus RTU mode
Protocol:
1200/2400/4800/9600/19200/38400 programmable
Baud rate:
8 bits
Data bits:
Even, odd or none (with 1 or 2 stop bit) programmable
Parity:
1 ~ 255 programmable
Address:
to show the value from RS485 command of master
Remote display:
1200M
Distance:
150Ω at last unit.
Terminate resistor:
Electrical Safety
AC 2.0 KV for 1 min, Between Power / Input / Output / Case
Dielectric strength:
≥100M ohm at 500Vdc, Between Power / Input / Output
Insulation resistance:
Between Power / Input / Relay, Analogue, RS485
Isolation:
EN 55011:2002; EN 61326:2003
EMC:
EN 61010-1:2001
Safety(LVD):
Environmental
0~60 ˚C
Operating temp.:
20~95 %RH, Non-condensing
Operating humidity:
≤100 PPM/˚C
Temp. coefficient:
-10~70 ˚C
Storage temp.:
Front panel: IEC 549 (IP54); Housing: IP20
Enclosure:
Mechanical
96mm(W) x 48mm(H) x 72mm(D)
Dimensions:
92mm(W) x 44mm(H)
Panel cutout:
ABS fire-resistance (UL 94V-0)
Case materiel:
Panel flush mounting
Mounting:
Plastic NYLON 66 (UL 94V-0)
Terminal block:
10A 300Vac, M2.6, 1.3~2.0mm
350g / 300g(Aux. Power Code: ADH or ADL)
Weight:
Power
AC115/230V,50/60Hz;
Power supply:
Optional: AC/DC 85~264V or 20~90V(RoHS version)
DC24V/30mA maximum in standard
Excitation supply:
Power Consumption: 4.5VA maximum
By EEPROM
Back up memory:

FRONT PANEL

Relay status
Indication
R L 1
Display screen
? ?
ENT/FN
Operation Key
DIMENSIONS
FRONT VIEW 48.0
96.0
PANEL CUT-OUT
44.0
92.0
+0.2
C1-01-2/7-2007-11-07
(16~12AWG)
2
Max. Hold status
M.H Comm. status
CO M
CI11
Front Key
function status
M.H
Mini. Hold status
2
Kg / c m
?
Engineer Unit
60.0
8.0
12.0
Dimensions: 96mm x 48mm x 72mm
Panel Cutout: 93mm x 45mm (advise)
+0.2
Unit: mm

INSTALLATION

The meter should be installed in a location that dose not exceed the
maximum operating temperature and provides good air circulation.
R L C O M
CI1
ENT/FN ? ? ? Kg/cn
PANEL CUT-OUT:
+0.2 +0.2
92 (W) x 44 (H) mm

CONNECTION DIAGRAM

Relay, Analogue o/p
or RS485 port can be
selected one only.
11 12 13 14 15 16
0~20mA
Excit.
Supply
0~10V
DC24V
SIGNAL INPUT
Please check the voltage of power supplied first, and then connect
to the specified terminals. It is recommended that power supplied to
the meter be protected by a fuse or circuit breaker.
Power Supply
6 7 8 9 10
L
N
G
Filter or Transformer
2 wire Transmitter connection
4~20mA 24Vdc
Excit.S
Input
11 12 13 14 15

FUNCTION DESCRIPTION

Input & Scaling Functions
(Option Code: AV)
Dual input types:
Voltage and Current Type are in one unit available in option. If the
customer specify the input coding for AV, the meter will be calibrated for
0~10V and 0~20mA in factory. The user can use in 0~10V or4(0)~20mA
by difference terminals connection(#11 & #13 for 0~10V or #12 & #13 for
4(0)~20mA) and programming in 【Ai.tYP】of【inPUt GroUP】.
Scaling function:
Setting the Lo.SC(Low scale) and Hi.SC(High scale) in【inPUt
GroUP】to relative input signal. Reverse scaling will be done too.
Please refer to the figure as below,
S C A L E D e fa u lt: L o .S C : 0 .0 0 , H i.S C : 1 0 0 .0 0
C h a n g e to L o .S C : 5 0 .0 0 , H i.S C : 1 9 9 .9 9
1 9 9 .9 9
R e ve rs e s lo p
1 0 0 .0 0
5 0 .0 0
0 .0 0
0 .0 0 % 5 0 .0 0 %
*Too narrow scale may course display lower resolution.
FIX HOLDER:
63 mm(L) / W M3
1.0~8.0 mm
Terminal blocks:
Relay
10A/300Vac, M2.6,
1.3~2.0mm (16~12AWG)
2
b c a
4 5 6 7 8 9 10
AC115V
AC230V
Analogue
FG
AC/DC 86~265V
ADH
output
ADL AC/DC 20~90V
AUX. POWER
A B
RS 485 port
1A Fuse
L AC115/230V
AC85~264V
N
G
RS485 Communication Port
Max. Distance: 1200M
Terminate Resistor
(at latest unit):
A B
120~300ohm/0.25W
(typical: 150ohm)
4 5 6
RS485 Port
IN P U T
1 0 0 .0 0 %
