Analogue output(option)
Accuracy:
≤± 0.1% of F.S.; 16 bits DA converter
Ripple:
≤± 0.1% of F.S.
Response time:
≤100 m-sec. (10~90% of input)
AC 2.0 KV between input and output
Isolation:
Specify either Voltage or Current output in ordering
Output range:
Voltage: 0~5V / 0~10V / 1~5V programmable
Current: 0~10mA / 0~20mA / 4~20mA programmable
Output capability:
Voltage: 0~10V: ≥ 1000Ω;
Current: 4(0)~20mA: ≤ 600Ω max
aOhs(output range high): Settable range: -19999~29999
Functions:
aOls(output range Low): Settable range: -19999~29999
aOlmt (output High Limit): 0.00~110.00% of output High
Digital fine adjust:
aOzro: Settable range: -38011~+27524
aOspn: Settable range: -38011~+27524
RS 485 Communication(option)
Modbus RTU mode
Protocol:
1200/2400/4800/9600/19200/38400 programmable
Baud rate:
8 bits
Data bits:
Parity:
Even, odd or none (with 1 or 2 stop bit) programmable
1 ~ 255 programmable
Address:
to show the value from RS485 command of master
Remote display:
1200M
Distance:
Terminate resistor:
150Ω at last unit.
Electrical Safety
AC 2.0 KV for 1 min, Between Power / Input / Output / Case
Dielectric strength:
Insulation resistance:
≥100M ohm at 500Vdc, Between Power / Input / Output
Isolation:
Between Power / Input / Relay / Analogue / RS485 / E.C.I.
EMC:
EN 55011:2002; EN 61326:2003
Safety(LVD):
EN 61010-1:2001
Environmental
0~60 ˚C
Operating temp.:
Operating humidity:
20~95 %RH, Non-condensing
Temp. coefficient:
≤100 PPM/˚C
Storage temp.:
-10~70 ˚C
Enclosure:
Front panel: IEC 549 (IP54); Housing: IP20
Mechanical
Dimensions:
96mm(W) x 48mm(H) x 120mm(D)
92mm(W) x 44mm(H)
Panel cutout:
Case material:
ABS fire-resistance (UL 94V-0)
Mounting:
Panel flush mounting
Plastic NYLON 66 (UL 94V-0)
Terminal block:
10A 300Vac, M2.6, 1.3~2.0mm
550g / 350g(Aux. Power Code: ADH or ADL)
Weight:
Power
Power supply:
AC115/230V,50/60Hz;
Optional:
Power consumption:
5.0VA maximum
By EEPROM
Back up memory:
FRONT PANEL
Relay status
Indication
R L 1
RL 2
2
RL3
RL4
Display screen
ENT/FN
?
?
Operation Key
C2-09
-2/8
(16~22AWG)
2
AC 85~264V, DC 100~300V, DC 20~56V
Max. Hold status
Comm. status
M.H
C OM
CI11
Control Input
CI2
CI3
status
M.H
Mini. Hold status
°C
?
Engineer Unit
CS2-T-2010-09-27
DIMENSIONS
FRONT VIEW
48.0
96.0
8.0
PANEL CUT-OUT
+0.2
44.0
+0.2
92.0
INSTALLATION
The meter should be installed in a location that
maximum operating temperature and provides good air circulation.
C O M
R
RL
C
R
C
R
C
°C
ENT/FN
?
?
?
PANEL CUT-OUT:
+0.2
+0.2
92
(W) x 44
(H) mm
CONNECTION DIAGRAM
Relay 1
Relay 2
Relay 3
Relay 4
a
c
b
c
a
b
c
a
a
21 22
23
24 25
26
27 28
29 30 31
ECI1
ECI2
ECI3 COM
11 12
13
14 15
1
2
3
A
B
b
Pt100Ω
External Control Input
T/C
SIGNAL
INPUT
Please check the voltage of power supplied first, and then connect to
the specified terminals. It is recommended that power supplied to the
meter be protected by a fuse or circuit breaker.
Power Supply
7
8
9 10
1A Fuse
L
L
N
N
G
G
Filter or Transformer
RS485 Communication Port
Max. Distance: 1200M
Terminate Resistor
(at latest unit):
120~300ohm/0.25W
A B
(typical: 150ohm)
31 32
33
RS485 Port
100.0
12.0
Dimensions: 96mm x 48mm x 120mm
Panel Cutout: 93mm x 45mm (advise)
Unit: mm
does
not exceed the
FIX HOLDER:
104 mm(L) / W M3
1.0~8.0 mm
RS 485
Analogue
output
port
Terminal blocks:
A
B
c
10A/300Vac, M2.6,
M2.6, 1.3~2.0mm
32
33
34
(16~22AWG)
4
5
6
7
8
9 10
AC115V
AC230V
AC 86~265V
FG
DC 100~300V
ADH
ADL
DC 20~56V
AUX. POWER
AC115/230V
AC85~264V
2
