INSTALLATION

Please check the specification, wire diagrams and functions on the label of the meter before
installation.
■ Dimensions & Panel Cut Out
FRONT VIEW
48.0
96.0
PANEL CUT-OUT
44.0
+0.2
92.0
■ Wiring Diagram
Please check the voltage of
power supplied first, and then
connect to the specified
terminals. Herein,
recommended that power
supplied with protection by a
fuse or circuit breaker to the
meter.
For input, RS485 and ECI
wiring, Herein recommended
using twin wire with shielding.
[CS2-VA Voltage / Current Meter Relay]
Relay 1 Relay 2 Relay 3
a c b c a b c
21 22 23 24 25 26 27 28
ECI1 ECI2 ECI3 COM
A1 A2 A3
1 2 3
SIGNAL INPUT
External Control Input
10 / 41
100.0
8.0
Dimensions: 96mm x 48mm x 120mm
Panel Cutout: 92mm x 44mm (advise)
+0.2
Unit: mm
Relay 4
RS 485 Analogue
port output
Terminal blocks:
a a c A B
10A/300Vac, M2.6,
1.3~2.0mm
29 30 31 32 33 34
(22~16AWG)
#A1~#A3:
4 5 6 7 8 9 10
20A/300Vac, M3.5,
1.3~3.5mm
AC115V
(22~12AWG)
AC230V
FG
ADH AC/DC 86~265V
AC/DC 20~56V
ADL
AUX. POWER
