Energized functions: Start delay / Energized & De-energized delay / Hysteresis
Start Delay
Inhibit
Inhibit
Hi Setting
Start Band
Relay
ON
Start Delay Time
Energized

Analogue output(option)

Please specify the output type either an o~10V or 4(0)~20mA in
ordering. The programmable output low and high scaling can be
based on various display values. Reverse slope output is possible by
reversing point positions.
Voltage: 0~5V / 0~10V / 1~5V programmable
Output range:
Current: 0~10mA / 0~20mA / 4~20mA programmable
Ao.HS(output range high): setting the Display value High
Functions:
to versus output range High(as like as 20mA in 4~20)
Ao.LS(output range Low): setting the Display value Low
to versus output range Low(as like as 4mA in 4~20)
SCALE
199.99
150.00
100.00
50.00
0.00
0.00%
The range between Ao.HS and Ao.LS should be over
20% of span at least; otherwise, it will be got less
resolution of analogue output.
Fine zero & span adjustment:
Users can get Fine Adjustment of analogue output by front key of
the meter. Please connect standard meter to the terminal of
analogue output. To press the front key(up or down key) of meter to
adjust and check the output of meter.
【Ao.Zro】: Fine Zero Adjustment for Analog Output;
Settable range: -38011~27524;
【Ao.Spn】: Fine Span Adjustment for Analog Output;
Settable range: -38011~27524;

ERROR MASAGE

BEFORE POWER ON, PLEASE CHECK THE SPECIFICATION AND
CONNECTION AGAIN.
SELF-DIAGNOSIS AND ERROR CODE:
: Display is positive-overflow (Signal is over display range)
: Display is negative-overflow (Signal is under display range)
: ADC is positive-overflow (Signal is higher than input 120%)
: ADC is negative-overflow (Signal is lower than input -120%)
/
/
/
/
/
C1-01-4/7-2007-11-07
Energized / De-energized
Delay & Hysteresis
Hi Setting
Hysteresis
Relay
ON
Energized
Set Scaling: Lo.SC: 0.00, Hi.SC: 199.99;
Output: Ao.LS: 50.00(Display Value Low),
Ao.HS: 150.00(Display Value High)
50.00% OUTPUT 100.00%
DESCRIPTION
: EEPROM occurs error
: Calibrating Input Signal do not process
: Calibrating Input Signal error
: Calibrating Output Signal do not process
: Calibrating Output Signal error

RS 485 Communication(option)

The RS485's protocol is Modbus RTU mode, and baud rate up to
38400 bps. It's convenience to remote monitoring, display for
reading.
RS 485 Modbus RTU Mode (up to 38400bps)
Analog Output 0~10V/0(4)~20mA
1 Relay Output:
Mode: High or Low Energized
Functions: Start delay / Energized &
COM COM
R L 1 R L 1
Display:
ENT/FN ◄ ▲ ▼ RPM EN ◄ ▲ ▼ Kg/cm Mode: Measuring Value / Maximum Hold /

Remote display:

The meter will show the value that received from RS485 command.
In past, The meter normally receive 4~20mA or 0~10V from AO or
digital output from BCD module of PLC .We support a new solution
that PV shows the value from RS485 command of master so that
can be save cost and wiring from PLC.
When the【dSPLY】set to be RS485, it means, the PV screen will
show the number from RS485 command & data. The data(number)
will be same as PV that will compare with set-point, analogue output
and ECI functions so that is to control analogue output, relay
energized and so on.
CS1 APPLICATION FOR REMOTE DISPLAY FROM RS485 COMMAND
RS 485 Modbus RTU Mode (up to 38400bps)
M.H M.H
R L 1 CO M R L 1 CO M
CI11 CI11
M.H M.H
2 2
◄ ▲ ▼ K g/ c m ◄ ▲ ▼ K g/ c m
ENT/FN ENT/FN
DISPLAY FLASH
De-energized delay / Hysteresis
Minimum Hold / Reading value from
RS485 command
RS485 wiring 1.2KM maximum
Terminate Resistor:
REMARK
(Please check the input signal)
(Please check the input signal)
(Please check the input signal)
(Please check the input signal)
(Please send back to
manufactory for repaired)
(Please process Calibrating
Input Signal)
(Please check Calibrating Input
Signal)
(Please process Calibrating
Output Signal)
(Please check Calibrating
Output Signal)
