6.2.10 Installing Feed Auger
Fingers, page 198
• Step
3, page 199
• Step
6, page 200
6.2.11 Removing Feed Auger
Fingers, page 200
6.2.11 Removing Feed Auger
Fingers, page 200
• Step
4, page 201
• Step
5, page 201
6.3.2 CR Feeder Deflectors, page
202
6.3.3 Replacing CR Feeder
Deflectors, page 203
7 Attaching Header to Combine,
page 205
• Table
7.1, page 205
7.1.1 Attaching Header to an
AGCO (Challenger, Gleaner, or
Massey Ferguson) Combine, page
205
• Step
1, page 205
7.1.2 Installing Reel Fore-Aft /
Header Tilt Selector Switch and
Harness, page 209
• Step
1, page 209
7.1.2 Installing Reel Fore-Aft /
Header Tilt Selector Switch and
Harness, page 209
215184
Summary of Change
• To avoid bodily injury or death from unexpected start-up or
fall of a raised machine, always stop engine and remove key
before leaving the operator's seat, and always engage safety
props before going under the machine for any reason.
Changed torque from 8.5 Nm (75 lbf∙in) to 9 Nm (80 lbf∙in).
Removed the following DANGER only because this procedure is
for the initial setup of the float module (the float module is not
operational at this point):
• To avoid bodily injury or death from unexpected start-up or
fall of a raised machine, always stop engine and remove key
before leaving the operator's seat, and always engage safety
props before going under the machine for any reason.
Changed torque from 8.5 Nm (75 lbf∙in) to 9 Nm (80 lbf∙in).
Added introductory statement:
• This section is for New Holland CR combines only. If operating
a New Holland CX combine, remove feed deflectors.
Changed the following WARNING to DANGER for consistency:
• To avoid bodily injury or death from unexpected start-up or
fall of a raised machine, always stop engine and remove key
before leaving the operator's seat, and always engage safety
props before going under the machine for any reason.
™
Added AGCO IDEAL
.
Added safety step:
• Shut down the engine, and remove the key from the ignition.
Revised step to mean tilting the feeder house, not the header, all
the way forward.
Revised the IMPORTANT as follows for consistency with similar
procedures:
vii
Internal Use
Only
Engineering
Tech Pubs
Engineering
Tech Pubs
Tech Pubs
ECN 57194
Tech Pubs
Product Support
Tech Pubs
Revision A
