Section
3.4 Attaching Reel Height Sensor,
page 133
• Figure
3.285, page 134
3.4 Attaching Reel Height Sensor,
page 133
• See NOTE below Figure
3.285, page 134
5.5 Unloading with a Combine,
page 162
• Step
10, page 162
6.1 Installing Filler Cap, page 175
• Step
2, page 175
• Step
3, page 176
• Step
4, page 176
6.1 Installing Filler Cap, page 175
6.1 Installing Filler Cap, page 175
• Step
6, page 176
• Step
9, page 177
6.2 FM100 Feed Auger
Configurations, page 178
6.2 FM100 Feed Auger
Configurations, page 178
6.2 FM100 Feed Auger
Configurations, page 178
6.2 FM100 Feed Auger
Configurations, page 178
215184
Summary of Change
• To avoid bodily injury or death from unexpected start-up or
fall of raised machine, always stop engine, remove key, and
engage safety props before going under machine for any
reason.
• ECN 58283: Added AGCO IDEAL
• Added arrows to the picture.
Added the following to the NOTE:
• For configuration (A), pointer (D) points to the FRONT of the
header.
• For configuration (B), pointer (D) points to the REAR of the
header.
Added reference to combine manual.
Updated picture to show change to hydraulic tank filler neck.
Removed step:
• "Apply hydraulic pipe controlled strength pipe thread sealant
®
(Loctite 565 or equivalent) to screws."
Updated picture to show change to hydraulic tank filler neck.
Narrow configuration as the standard configuration: Added
™
AGCO IDEAL Series
Narrow configuration: Added information about the quantity of
flightings and fingers.
Medium configuration as the standard configuration: Added the
following combines:
• Case IH 2300/2500 Series
• Case IH 5/6/7150, 7/8/9250
• CLAAS 7000/8000
• John Deere S76/77/78/790
• New Holland CR 10.80/10.90
• Rostselmash Torum 760/780
Medium configuration as the standard configuration:
iv
™
to picture legend.
Internal Use
Only
ECN 58283
Tech Pubs
Product Support
Tech Pubs
ECN 57856
ECN 59259
ECN 57856
ECN 59301
Tech Pubs
Engineering
Tech Pubs
Tech Pubs
Revision A
