Loading header onto flat deck
3. Approach header and line up forks (A) with fork slider
channels (B).
NOTE:
When possible, approach header from the underside to
minimize potential for damage to the unit.
4. Slide forks (A) in as far as possible.
IMPORTANT:
Avoid damage to gearbox (A) when setting the unit down.
5. Approach the trailer slowly, and raise the forklift until the
header clears the trailer deck by 102–204 mm (4–8 in.).
6. Lower the header onto the trailer deck, and back the
forklift away slowly.
215184
LOADING HEADER FOR TRANSPORT TO DEALERSHIP
145
B
A
Figure 4.3: Fork Slider Channels
A
Figure 4.4: View from below Header
Figure 4.5: Header on Flat Deck Trailer
1017270
1017034
