IPC974 Series User's Manual
No. Description
1 2 x Antenna opening
2 1 x HDD drive bay(default, support
2 x 2.5" HDD/SSD)
3 1 x HDD drive
support 2 x 2.5" HDD/SSD)
4 HDD access/power LED
5 Power on/off switch
6 Extension Window
(1)Blank cover (default)
(2)1 x Wifi kit and/or (3) 1 x USB
dongle kit
(4)AX92902+AX93287: 1 x
10/100/1000 Mpbs Ethernet
module (Intel® i210-AT)
(5) AX92903: CANBus module
(6) AX92906: 1 x RS-232 module
7 4-pin terminal block
8 AT/ATX mode switch
9 Line out
10 Reset switch
10
No.
11
12
bay(optional, 13
14
15
16
17
18
19
Description
2-pin connector output for remote power
on/off switch
2 x USB 2.0
1 x 10/100/1000Mbps ethernet(i211-AT)
2 x USB3.0
1 x 10/100/1000Mbps ethernet(i219LM)
2 x USB3.0
VGA
HDMI
Extension System I/O Module
(1) AX93511: 4 x RS-232/422/485 module
(default RS-232)
(2) AX93512: 2 x RS-232/422/485 with
isolated 1.5kVDC & 8-in/8-out with
isolated 1.5kVDC DIO module
(3) AX93516: 4 x RS-232/422/485 with
isolated 2kVDC module
(4) AX93519: 1 x 10/100/1000 Mbps (Intel®
i211-AT) Ethernet, 2 x RS-232/422/485,
and 2 x USB 3.0 module
(5)Blnak I/O cover
Expansion Interface
(1) AX96410: 1 PCIe x16 + 3 PCIe x4
(2) AX96411: 1 PCIe x16 + 1 PCIe x4 + 2
PCI
1 x Terminal ground
