Temporarily saves the created rule.
Changes the order of the created rules.
You can enter address ranges in the input fields for the IP address.
Example of address ranges: 192.168.0.100-192.168.0.110 or 192.168.0.20/30
Address listings are not possible!
In the input fields for the ports, you can enter ranges or enumerations.
Example of a port range: 502-504
Example of port enumeration: 502,677,555
Both, range and enumeration can not be used simultaneously in the same field.
Ranges must be separated by a hyphen (-) and enumerated by comma (,).
No spaces between the elements to be separated!
The input of IP and port is not mandatory. If neither an IP nor a port is specified, a rule applies only to the selected
interfaces.
