Range Extender Antenna
Use the Range Extender Antenna (Figure 1-8) to ensure optimal transmission and reception
quality for situations where the integrated antennas are shielded, such as:
•
The wireless device is close to metal surfaces.
•
The wireless device is installed in a hidden location, such as in a cabinet.
•
Objects shield the wireless device.
The Range Extender antenna has a mounting bracket and a base for vertical positioning that
allows you to place the antenna on top of a table or cabinet, or attach it to the wall or ceiling.
To connect an antenna to the PC Card, insert the connector into the socket on the extended
side of the PC card. To protect the socket from dust, it is shielded with a cap.
Typically, the Range Extender Antenna is used with a desktop client. See the "Range
Extender Antenna Specifications" section on page A-6 for the antenna specifications.
!
CAUTION
Figure 1-8: Range Extender Antenna
To avoid damage, do not place the Range Extender Antenna
on top of, or close to a monitor. Many computer monitors
have a degauss option. An electromagnetic discharge that
may occur when degaussing the monitor may damage the
antenna.
Optional Antennas
Wireless Network Configurations 1-15
