Table 1. Acronyms (continued)
SRC = source
Stg = stage
Stnd = standard
STP = SETPOINT
Sw = switch
SZ = single-zone (unit airflow)
TCI = Tracer communications interface (module)
Press = pressure
Temp = temperature
UCM = Unit Control (Module)
Unocc = unoccupied
VAV = variable air volume
VCM = ventilation control module
VDC = volts DC
Ventil = ventilation
VFD = variable frequency drive
™
Table 2. IntelliPak points list
Unit
Module Analog Inputs
RTM ASE damper min pos
Evap temp sensor
SCM
Sat cond temp sensor
Evap temp sensor
MCM
Sat cond temp sensor
MWU temp sensor
Heat Module
Modulating heat actuator
Return air temp sensor
ECEM
Return air humidity sensor
VOM N/A
4 inputs from these choices:
Occ zone cool setpt
Occ zone heat setpt
Unocc zone cooling setpt
GBAS Unocc zone heat set
Min O/A flow setpt
Sup air cooling setpt
Sup air heating setpt
Sup air static pres setp

UCM Control System

The IntelliPak™self-contained units are controlled by a
microelectronic control system that consists of a network
of modules and are referred to as Unit Control Modules
(UCM).
The unit size, type, heating functions, peripheral devices,
options, exhaust capabilities, etc. determine the number
PKG-SVP01E-EN
Analog Outputs Binary Inputs
Emergency stop
External auto/stop
Unoccupied/occupied
O/A damper actuato Alarm
Dirty filter
VAV changeover
Supply airflow proof
Cond fan speed
Low pressure control Compressor
proving
(Low ambient)
Cond fan speed
Low pressure control- ckt 1 & 2
Compressor proving- ckt 1 & 2
(Low ambient- ckt 1 & 2)
Heat 1 relay
Low entering air Heat 2 relay
Heat 3 relay
N/A VOM mode A, B, C, D, E contacts
N/A Demand limit contacts
Table 1. Acronyms (continued)
VOM = ventilation override module
VVDA=Variable Speed Fan (VAV)/Discharge Air Temp Control
W/ = with
w.c. = water column
WU = warmup
XL = across-the-line start

Glossary of Terms

For a glossary of terms see
review these definitions since they are used throughout
this document and the Installation, Operation,
Maintenance Guide (IOM). Knowledge of these terms is
essential in gaining an understanding of how these units
operate.
™
IntelliPak Points List
and type of modules that a particular rooftop unit may
employ.
These modules perform specific unit functions using
proportional/integral control algorithms.They are
mounted in the unit control panel and are factory wired to
their respective internal components.
By processing analog and binary inputs, each module
supplies outputs in the form of modulating voltages (from
General Information
"Glossary, " p. 48. Carefully
Binary Outputs
VAV box drive max
CV unoccupied mode indicator
Alarm
Fan run request
Water pump request
Compressor relay Condenser fan A,
B
Compressor relay
Condenser fan 1A, 1B, 2A, 2B
VOM relay
Dirty filter
Refrigeration fail relay
Heat fail relay
Fan fail relay
TBD relay
