Programming Status
Active Min OA Flow Setpoint from
REMOTE MIN POS POT INPUT
1. Pressing the NEXT key will scroll forward through the screens.
Active Supply Air Pressure STP From
HI (KEYPAD SETPOINT MENU) is
1. Pressing the NEXT key will scroll forward through the screens.
Active Supply Air Pressure Setpoints
Hi Limit: 40 IWC
1. Pressing the NEXT key will scroll forward through the screens.
End of Submenu (NEXT) to Enter SETUP
1. Pressing the NEXT key will scroll forward through the screens.
Controlling Sensor Status Submenu
Press ENTER to View Data in This Submenu
1. Pressing the NEXT key will scroll forward through the screens.
Active Supply Air Heating Temp Sensor Input From
RTM ZONE TEMP INPUT
1. Pressing the NEXT key will scroll forward through the screens.
Active Daytime WU Temp Sensor Input From
RTM ZONE TEMP INPUT
1. Pressing the NEXT key will scroll forward through the screens.
Active Occupied Zone Temp Sensor Input From
HI (KEYPAD) SETPOINT MENU
1. Pressing the NEXT key will scroll forward through the screens.
Active Unocc Zone Temp Sensor Input From
RTM ZONE TEMP INPUT
1. Pressing the NEXT key will scroll forward through the screens.
Active Morning WU Temp Sensor Input From
RTM ZONE TEMP INPUT
1. Pressing the NEXT key will scroll forward through the screens.
Active Zone Reset Sensor Input From
RTM ZONE TEMP INPUT
1. Pressing the NEXT key will scroll forward through the screens.
18
342.0 CFM
2.0 IWC
Deadband: 0.5 IWC
is 50.0 F
is 82.0 F
Is 90.0 F
is 75.0 F
is 82.0 F
is 82.0 F
Used With: Units with VCM module only
Possible Values: HI (Keypad) Setpoint Menu, GBAS
0-5 VDC Module
Setpoint Range: 0 to max unit airflow
Used With: Units with IGV or VFD only.
Possible Values: HI (Keypad) Setpoint Menu, GBAS
Module
Used With: Units with IGV or VFD only.
Possible Values: High Limit = 1.6-4.7 IWC;
Deadband = 0.1-2.0 IWC
Possible Values: RTM Supply Air Temp Input, ICS
(Tracer Summit™)
Used With: Units with Electric, Hydronic or External
Heat installed.
Possible Values: RTM Zone Temp Input, NSB Zone
Sensor Setpoint Input, RTM Aux Temp Input, ECEM
return Air Temp Input, ICS (Tracer Summit™)
Sensor Range: -40 to 200 F
Used With: Units with Electric, Hydronic or External
Heat with DWU installed.
Possible Values: RTM Zone Temp Input, NSB Zone
Sensor Setpoint Input, RTM Aux Temp Input, ECEM
return Air Temp Input, ICS (Tracer Summit™)
Sensor Range: -40 to 200 F
Possible Values: RTM Zone Temp Input, NSB Zone
Sensor Setpoint Input, RTM Aux Temp Input, ECEM
return Air Temp Input, ICS (Tracer Summit™)
Sensor Range: -40 to 200 F
Used With: Units with Electric, Hydronic or External
Heat with MWU installed.
Possible Values: RTM Zone Temp Input, NSB Zone
Sensor Setpoint Input, RTM Aux Temp Input, ECEM
return Air Temp Input, ICS (Tracer Summit™)
Sensor Range: -40 to 200 F
Possible Values: RTM Zone Temp Input, NSB Zone
Sensor Setpoint Input, RTM Aux Temp Input, ECEM
return Air Temp Input, ICS (Tracer Summit™)
Sensor Range: -40 to 200 F
