Programming Status
Temp Measured By Sensor Connected To
WSM ENT WATER TEMP INPUT
1. Press the NEXT key until the following screen is displayed.
Temp Measured By Sensor Connected To
WSM MIXED AIR TEMP INPUT
1. Press the NEXT key until the following screen is displayed.(if applicable)
Temp Measured By Sensor Connected To
WSM ENT COND WATER TEMP INPUT
1. Press the NEXT key until the following screen is displayed. (if applicable)
Temp Measured By Sensor Connected To
VCM MODULE AUX TEMP INPUT
1. Press the NEXT key until the following screen is displayed.
Compressor Module Ckt 1
Evap Temp 75.0 Sat Cond Temp
1. Pressing the NEXT key will scroll forward through the screens.
Compressor Module Ckt 2
Evap Temp 72.0 Sat Cond Temp
1. Pressing the NEXT key will scroll forward through the screens.
Compressor Module Ckt 3
Evap Temp 72.0 Sat Cond Temp
1. Pressing the NEXT key will scroll forward through the screens.
Compressor Module Ckt 4
Evap Temp 72.0 Sat Cond Temp
End of Submenu (NEXT) to Enter SETUP
1. Press the NEXT key until the following screen is displayed.
Misc Input Status Submenu
Press ENTER to View Data in This Submenu
1. Press the NEXT key until the following screen is displayed. (if applicable)
RTM Supply Airflow Proving Inut:
1. Press the NEXT key until the following screen is displayed.
RTM Remote Min Position Pot Input
1. Press the NEXT key until the following screen is displayed. (if applicable)
RTM Supply Air Pressure Input
1. Press the NEXT key until the following screen is displayed.
20
60.1 F
51.7 F
64.9 F
50.0 F
81.0 F
87.0 F
87.0 F
87.0 F
FLOW
0%
2.1 IWC
Used With: On water-cooled units only.
Used With: On water-cooled units only.
Used With: On water-cooled units only.
Used With: Units with a VCM installed and O/A
preheater enabled.
Used With: SCWF/SIWF 42-80 tons or SCRF/SIRF
50-60 tons only.
Used With: SCWF/SIWF 65-80 tons.
Possible Values: Flow, No Flow
Used With: Units when minimum position pot is
assigned to function.
Possible Values: 0-100%
Used With: Units with IGV or VFD, or units without
IGV or VFD and supply air pressure is present.
