Ventilation Override Definition
VCM Preheater State
1. Press the NEXT key until the following screen is displayed.
Ventilation Override Definition
VO Relay
1. Press the NEXT key until the following screen is displayed.
Ventilation Override Definition
Enter Password to Lock Definition:
1. Press the NEXT key until the following screen is displayed.
Note: After locking a MODE (by entering the password), the display for that MODE becomes "Reporting" only and the
definition can not be changed unless the Ventilation Override Module is replaced. If the password was entered,
pressing the NEXT key will scroll through the previous screens to confirm the selected choices for each mode as
follows:
Ventilation Override
Supply Fan
Ventilation Override
Supply Fan
1. Follow the preceding steps used to program MODE "A" to program MODE B", "C", "D", and "E"
if modifications are needed. After all of the Ventilation Override Definitions have been
programmed, pressing the NEXT key will advance to the following screen.
End of Submenu (NEXT) to Enter SETUP
1. Press the NEXT key until the following screen is displayed.

GBAS Module I/O Assignments

GBAS 0 - 5 VDC Module I/O Assignments
Press ENTER to Review or Adjust
1. Press the NEXT key until the following screen is displayed.
GBAS (0 - 5 VDC) Analog Input 1
1. Press the + or - key until the proper selection is displayed for the number 1 assignment.
2. Press the ENTER key to confirm this choice. Only one input definition can be assigned to each
input and they can not be duplicated.
3. Press the NEXT key to advance to the number 2 input assignment screen and repeat steps 1
& 2. Follow these steps for input assignments 3 and 4.
4. Press the NEXT key until the following screen is displayed.
PKG-SVP01E-EN
Mode A
Mode B
NOT ASSIGNED
Mode A
IN CONTROL
Mode A
ENERGIZED
Mode A
Is Locked
Assignment
Programming SETUP
Used With: All Units when VOM is installed and
OA preheater function is enabled
Factory Presets: Refer to Definitions
Possible Values: OFF, IN CONTROL
Used With: All Units when VOM is installed
Factory Presets: Refer to Definitions
Possible Values: ENERGIZED/DEENERGIZED
Used With: Units a VOM
Factory Presets: Not Locked
Possible Values: + (Plus), -(Minus)
Used With: All Units when VOM and VO mode
is locked
Factory Presets: Refer to the Definitions
Possible Values: N/A
Used With: All Units
Factory Presets: Refer to the Definitions
Possible Values: ON, OFF
Used with: All Units when GBAS 0-5 VDC is
installed.
Used with: All Units when GBAS is installed.
Factory Presets: Not Assigned
Possible Values: Not Assigned, Unoccupied
Zone Cooling SETPOINT
Occupied Zone Heating SETPOINT
Unoccupied Zone Heating SETPOINT
Space Static Pressure SETPOINT, SA Static
Pressure SETPOINT, Min OA Flow SETPOINT,
Morning Warmup SETPOINT, Econ Dry Bulb
Enable SETPOINT, Minimum Position SETPOINT,
Occupied Dehumid SETPOINT, Unoccupied
Dehumid SETPOINT, Supply Air Reheat
SETPOINT, Occupied Humidification SETPOINT,
Unoccupied Humidification SETPOINT
