Trane IntelliPak Signature Series Programming Manual page 23

Morning Warmup Function:
Morning Warmup Type:
1. Press the NEXT key until the following screen is displayed (if applicable).
Supply Air Tempering Function:
Warm Up Outside Air Used For Ventilation
1. Press the NEXT key until the following screen is displayed.
Unocc Mech Cooling Function:
Unocc Mech Cooling Function:
Unocc Heating Function:
1. Press the NEXT key until the following screen is displayed (if applicable).
OA Preheater Output Control:
Activate If Preheat Temp Below SETPOINT
1. Press the NEXT key until the following screen is displayed
Demand Limit Definition:
Cooling: 100%
1. Press the NEXT key until the following screen is displayed.
Demand Limit Definition:
Cooling: 100%
1. Press the NEXT key until the following screen is displayed.
Compressor Lead/Lag Function:
Vary Staging Order To Distribute Runtime
1. Press the NEXT key until the following screen is displayed.
Reduce Multi-Unit Startup Power Demand
After Power-Up, Delay Unit Start:
1. Press the NEXT key until the following screen is displayed (if applicable).
Coil Frost Cutout Temperature:
Compressors If Evap Temp Is Below:
1. Press the NEXT key until the following screen is displayed.
End of Submenu (NEXT) to Enter SETUP
1. Press the NEXT key to leave the submenu and show following screen.
VAV Control Functions Submenu
Press ENTER to Review or Adjust
1. Press the NEXT key until the following screen is displayed.
PKG-SVP01E-EN
ENABLED
FULL CAPACITY
DISABLED
ENABLED
OR
ENABLED
ENABLED
ENABLED
Heating: 100%
DISABLED
0 Sec
Shut off
30 F
Programming SETUP
Used With: Units when Electric, or Hydronic
Heat is installed.
Factory Presets: Function = Enabled; MWU
Type = Full Capacity
Possible Values: Function = Enabled,
Disabled; MWU Type = Full Capacity, Cycling
Capcity
Used With: All Units when Hydronic Heat is
installed
Factory Preset: Function = Disabled
Possible Values: Function = Enabled, Disabled
Used With: Cooling-only units
Factory Preset: Cooling and Heating Function
= Enabled
Possible Values: Cooling and Heating Function
= Enabled, Disabled
Used With: All Units with electric, hydronic, or
external heat is installed
Factory Presets: Cooling & Heating =Enabled
Possible Values: Cooling & Heating = Enabled,
Disabled
Used With: Units with VCM installed
Factory Preset: Control = Disabled
Possible Values: Control = Enabled, Disabled
Factory Presets: None
Possible Values: Cooling = None, 50 or 100%
Used With: Units Electric or Hydronic heat.
Factory Presets: None
Possible Values: Cooling/Heating: None, 50 or
100%
Factory Preset: Function = Disabled
Possible Values: Function = Enabled, Disabled
Factory Preset: Start = 0 Seconds
Possible Values: Start = 0-255 Seconds
Factory Preset: 30 F
Possible Values: 25 F to 35 F
23
