Programming SETUP

After the unit is installed, the control module must be
programmed with certain SETUP information in order to
operate and function properly.The data necessary for unit
operation will vary depending on certain factors such as
unit size, type, and installed options.
This section of the manual provides step by step
instructions for programming this information. Also
provided are instructions for checking unit operating
status, accessing and clearing diagnostics, and
performing service tests.
Some of the displays shown in this manual may not
appear on the Human Interface (HI) LCD screen during
programming. Only the applicable screens for the specific
unit options and operating parameters will be displayed.
Ignore the steps that do not apply to your unit and
application, and move on to the next applicable set of
instructions in the manual. Continue this process until all
applicable screens are programmed with the required
information.

SETUP Menu

The SETUP menu is used to input initial operating
information such as control parameters, SETPOINT source
selection, sensor source selections, ventilation override
definitions, functions enable/disable, status, text display
Display Text in:
Display Units Using:
1. Press the NEXT key until the following screen is displayed.
Unit Control:
Unit Address:
1. Pressing the NEXT key will bypass this section.
General Unit Functions Setup Submenu
Press ENTER to Review or Adjust
1. Pressing the NEXT key will bypass this section.
Supply Fan VFD Mode:
1. Pressing the NEXT key will bypass this section.
If Remote Panel Mode Input Not Present:
System Mode: AUTO
1. Press the NEXT key until the following screen is displayed (if applicable).
Daytime Warmup Function:
1. Press the NEXT key until the following screen is displayed.
22
ENGLISH LANGUAGE
ENGLISH NOTATION
LOCAL
31
BYPASS
DISABLED
(language), temperature display (C or F), and system
tuning parameters. When a SETUP screen is displayed for
30 minutes without a key being pressed, the LCD screen
will revert to the appropriate power-up display. If this
happens, press the SETUP key again to return to the
SETUP menu.
Note: Many of the screens displayed in this section are
applicable only for the options that are installed in
the unit and may not be visible on your unit.
Press the SETUP key to begin viewing or modifying the
SETUP screens.
If a screen is not visible on the Unit Human Interface
Module, refer to the "Used With" information listed to the
right of each screen in this book.
Follow this procedure when viewing a screen that requires
modification:
1. Press the + or - key until the proper value displays.
2. Press the ENTER key to confirm your choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 if there are addtional values on the
same screen that require changing.

SETUP Menu Screens

Press the SETUP key to display the following screens.
Used With: All Units
Factory Presets: Text and Units: ENGLISH
Language, ENGLISH Notation
Possible Values: Text: ENGLISH, FRENCH,
SPANISH; Units: ENGLISH NOTATION, SI
NOTATION
Used With: Units with TCI, LCI or BCI module
Factory Presets: Control = Local, Address = 1
(only shown if TCI installed)
Possible Values: Unit Control = Local, BAS/
NETWORK, Unit address= 0-31 (only shown if
TCI installed)
Used With: Units with VFD and bypass
Factory Presets: Mode = Normal, Address = 1
Possible Values: Mode = Normal, Bypass
Possible Values: System Mode = OFF/AUTO
Factory Preset: Disabled
Possible Values: Daytime Warm up Function:
ENABLED, DISABLED
