Programming SETUP
Supply Air Temp Reset Type:
Cooling:
1.
Press the NEXT key until the following screen is displayed.
Supply Air Temp Reset Type:
Cooling: ZONE
1.
Press the NEXT key until the following screen is displayed.
Supply Air Temp Zone
Start Temp: 72 F
1.
Press the NEXT key until the following screen is displayed.
Supply Air Temp Outside Air
Start Temp: 90 F
1.
Press the NEXT key until the following screen is displayed.
Supply Air Temp Zone
Maximum Amount of Reset Applied:
1.
Press the NEXT key until the following screen is displayed.
Supply Air Temp Outside Air
Maximum Amount of Reset Applied:
1.
Press the NEXT key until the following screen is displayed.
Supply Air Temp Outside Air
Start Temp:
10 F
1.
Press the NEXT key until the following screen is displayed.
Supply Air Temp Zone
Start Temp:
65 F
1.
Press the NEXT key until the following screen is displayed.
Supply Air Temp OA
Maximum Amount of Reset Applied:
1.
Press the NEXT key until the following screen is displayed.
Supply Air Temp Zone
Maximum Amount of Reset Applied:
1.
Press the NEXT key until the following screen is displayed.
VAV Box Max Stroke Time:
1.
Press the NEXT key until the following screen is displayed.
Max Occupied IGV/VFD Command:
1.
Press the NEXT key until the following screen is displayed.
24
ZONE
Heating: ZONE
Reset For Cooling:
End Temp:
69 F
Reset For Cooling:
End Temp:
70 F
Reset For Cooling:
Reset For Cooling:
Reset For Heating:
End Temp:
60 F
Reset For Heating:
End Temp:
68 F
Reset For Heating:
10 F
Reset For Heating:
10 F
0 Min
100%
Used With: Units without heat
Factory Presets: None
Possible Values: Cooling = None, Zone, OA
Used With: Units with hydronic heat
Factory Presets : None
Possible Values: Cool/Heat = None, Zone, OA
Used With: Units when Zone Cooling Reset is
selected.
Possible Values: Cooling/Heating = Zone, OA;
Start Temp Zone = 209 OS = 70; End Temp Zone
= 210 OA = 71
Possible Values: Cooling/Heating = Zone, OA;
Start Temp Zone = 209 OS = 70; End Temp Zone
= 210 OA = 71
Used With: All Units when Outside Air cooling
reset is selected.
5 F
Possible Values: SAT = Zone, OA; Reset
(Zone) = 72; Reset (OA) = 72
Used With: All Units when Outside Air cooling
reset is selected.
5 F
Possible Values: SAT = Zone, OA; Reset
(Zone) = 72; Reset (OA) = 72
Used With: All Units when Outside Air heating
reset is selected.
Factory Presets: Start = 10 F; End = 60 F
Possible Values: Start OA Temp = 73 F; End
OA Temp = 74 F
Used With: Units when Zone Air heating reset
is selected.
Factory Presets: Start = 65 F, End = 68 F
Possible Values: Start OA Temp = 211; End
OA Temp = 212
Used With: All Units when Zone Heating is
selected.
Possible Values: SAT temp = Zone, OA; Zone
Reset = 75; OA Reset = 75
Used With: All Units when outside heating is
selected.
Possible Values: SAT temp = Zone, OA; Zone
Reset = 75; OA Reset = 75
Factory Presets: 6 Min
Possible Values: 0 to 10
Used With: Units with IGV/VFD installed
Factory Presets: 100%
Possible Values: 0 to 100%
PKG-SVP01E-EN
