For Default OA Damper Min Position, Use
Setpoint From: HI (KEYPAD) SETPOINT MENU
1.
Press the NEXT key until the following screen is displayed.
For Min Outside Air Flow Rate Ctrl, Use
Setpoint From: HI (KEYPAD) SETPOINT MENU
1.
Press the NEXT key until the following screen is displayed.
For Supply Air Pressure Control, Use
Setpoint From: HI(KEYPAD) SETPOINT Menu
1.
Press the NEXT key until the following screen is displayed (if applicable)
End Of Submenu (NEXT) To ENTER SETUP
1.
Press the NEXT key to leave the submenu and show following screen.
PKG-SVP01E-EN
SETPOINT Menu
Used With: All Units when an airside or
waterside economizer or VCM is installed.
Factory Presets: HI (KEYPAD) SETPOINT
MENU
Possible Values: HI (KEYPAD) SETPOINT
MENU, REMOTE MIN POS POT INPUT
Used With: Units with a VCM or GBAS installed.
Factory Presets: HI (KEYPAD) SETPOINT
MENU
Possible Values: HI (KEYPAD) SETPOINT
MENU, GBAS 0-5VDC Module
Used With: AUnits with a IGV or VFD and GBAS
installed.
Factory Presets: HI (KEYPAD) SETPOINT
Menu
Possible Values: HI (KEYPAD) SETPOINT
MENU, GBAS 0-5VDC Module
Used With: All units.
39
