Warnings, Cautions and Notices

Warnings, Cautions and Notices.
cautions and notices appear at appropriate intervals
throughout this manual. Warnings are provided to alert
installing contractors to potential hazards that could result
in death or personal injury. Cautions are designed to alert
personnel to hazardous situations that could result in
personal injury, while notices indicate a situation that
could result in equipment or property-damage-only
accidents.
Your personal safety and the proper operation of this
machine depend upon the strict observance of these
precautions.
Read this manual thoroughly before operating or servicing
this unit.
Warnings, Cautions, and Notices appear at
ATTENTION:
appropriate sections throughout this literature. Read
these carefully:
Indicates a potentially hazardous
WARNING
situation which, if not avoided, could
result in death or serious injury.
Indicates a potentially hazardous
CAUTION
s
situation which, if not avoided, could
result in minor or moderate injury. It
could also be used to alert against
unsafe practices.
Indicates a situation that could result in
NOTICE:
equipment or property-damage only
accidents.

Introduction

Note: One copy of the appropriate service literature
(Installation, Owner, and Diagnostic Manual) ships
inside the control panel of each unit.
Use this manual for IntelliPak
models SCWF/SIWF , SCRF/SIRF , SCWG/SIWG, and SIWG/
SIRG.

Overview

This manual is divided into multiple sections based on the
unit's human interface (HI) panel format. Each section
provides step by step instructions for programming the
unit using the HI. In addition, each section provides
specific information about the system operating
parameters and their related HI screens, in the order they
appear when scrolling through the HI.
By carefully following the screen layout in this manual
while referencing the HI panel, the user can monitor
operating status, set specific operating parameters, and
diagnose system problems.
Some screens shown in this manual are dependent on unit
options and/or model configuration.Therefore, some
screens in this manual may not appear on a particular
© 2015Trane All rights reserved
Note that warnings,
™
commercial self-contained
unit's human interface panel. Screens that are
configuration-dependent are labeled as such. Follow the
appropriate steps for each screen as it appears and
proceed through each section.
Refer to the table of contents and index for specific topics
contained in this manual and supporting manuals.
Complete the "Start-Up" procedures in the applicable
Installation, Owner, and Diagnostic (IOD) manual before
attempting to operate or service this equipment to
minimize the risk of improper operation.
Note: The procedures discussed in this manual should
only be performed by qualified, experienced HVAC
technicians.

Revision History

PKG-SVP01E-EN
• Updated model numbers to include -90, -CO and -C1.

Trademarks

Echelon, the Echelon logo, 3120, 3150, LON, LonBuilder,
NodeBuilder, LonLink, LonMaker, LonManager, LonPoint,
LonResponse, LonSupport, LonTalk, LONWORKS,
LonUsers and Neuron are registered trademarks of
Echelon Corporation.
