Trane IntelliPak Signature Series Programming Manual page 41

Configuration - Model Num Digit
Water Flow Switch
1. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
Heating Type:
1. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
Unit Capacity
1. Press the NEXT key until the following screen is displayed.
Note: The possible value for unit capacity is dependent oupon the unit size (tons).
Configuration - Model Num Digit
Power Exhaust
1. Press the NEXT key until the following screen is displayed.
Note: This option is currently not available on commercial self-contained units, but this screen still displays..
Configuration - Model Num Digit
Air Economizer
1. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
Air Temp/Vol Ctrl SA CTRL WITH IGV/VFD
1. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
Supply Fan VFD Bypass
1. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
Comparative Enthalpy
1. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
GBAS 0-5 VDC Module
1. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
Ventilation Override (VOM)
1. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
Ventilation Ctrl
1. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
TCI4 Communications Module
1. Press the NEXT key until the following screen is displayed.
PKG-SVP01E-EN
29
INSTALLED
20
HYDRONIC
6, 7
72
23
NONE
28
INSTALLED
9
9
INSTALLED
28
INSTALLED
33
INSTALLED
33
INSTALLED
28
TRAQ DAMPERS
33
INSTALLED
Programming Configuration
Used With: Units on all water-cooled units or units
with waterside economizer and water flow switch.
Possible Values: Installed, Not Installed
Possible Values: Hydronic, Electric None, External
Used With: All Units
Possible Values: 20-80
Used With: All Units
Possible Values: None, 100% with Statitrac, 50%/
100% without Statitrac
Used With: All Units
Possible Values: Installed, Not Installed
Used With: All Units
Possible Values: SA Control with IGV/VFD, Zone
Control, No IGV/VFD or SA Control, No IGV/VFD
Used With: Units with SA Control and IGV/VFD
Possible Values: Installed, Not Installed
Used With: All IntelliPak™ II Units
Possible Values: Installed, Not Installed
Used With: All Units
Possible Values: Installed, Not Installed
Used With: All Units
Possible Values: Installed, Not Installed
Used With: All Units
Possible Values: Traq™ Dampers, Standard
Dampers
Used With: All Units
Possible Values: nstalled, Not Installed
41
