Programming SETUP
Actuator Setup
Max Stroke Time
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Min Voltage
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Voltage
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Direct/Reverse Act
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Stroke Time
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Min Voltage
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Voltage
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Direct/Reverse Act
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Stroke Time
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Min Voltage
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Voltage
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Direct/Reverse Act
1. Press the NEXT key until the following screen is displayed.
34
Hydronic
150 Sec
Hydronic
2.0 VDC
Hydronic
10.0 VDC
Hydronic
DIRECT ACTING
Num 1 Low Ambient
60 Sec
Num 1 Low Ambient
2.0 VDC
Num 1 Low Ambient
10.0 VDC
Num 1 Low Ambient
DIRECT ACTING
Num 2 Low Ambient
60 Sec
Num 2 Low Ambient
2.0 VDC
Num 2 Low Ambient
10.0 VDC
Num 2 Low Ambient
DIRECT ACTING
Used With: All Units when Hydronic Heat is
installed.
Factory Presets: 150 Seconds
Possible Values: 1 - 255 Seconds
Used With: All Units when Hydronic Heat is
installed.
Factory Presets: 2.0 VDC
Possible Values: 0.0 to 9.9 Volts DC
Used With: All Units when Hydronic Heat is
installed.
Factory Presets: 10.0 VDC
Possible Values: 0.1 to 10.0 Volts DC
Used With: All Units when Hydronic Heat is
installed.
Factory Presets: DIRECT ACTING
Possible Values: DIRECT ACTING, REVERSE
ACTING
Used With: Air-cooled units low ambient
damper installed.
Factory Presets: 60 Seconds
Possible Values: 1 - 255 Seconds
Used With: Air-cooled units low ambient
damper installed.
Factory Presets: 2.0 VDC
Possible Values: 0.0 to 9.9 Volts DC
Used With: Air-cooled units low ambient
damper installed.
Factory Presets: 10.0 VDC
Possible Values: 0.1 to 10.0 Volts DC
Used With: Air-cooled units low ambient
damper installed.
Factory Presets: Direct Acting
Possible Values: Direct Acting, Reverse Acting
Used With: Air-cooled units low ambient
damper installed.
Factory Presets: 60 Seconds
Possible Values: 1 - 255 Seconds
Used With: Air-cooled units low ambient
damper installed.
Factory Presets: 2.0 VDC
Possible Values: 0.0 to 9.9 Volts DC
Used With: Air-cooled units low ambient
damper installed.
Factory Presets: 10.0 VDC
Possible Values: 0.1 to 10.0 Volts DC
Used With: Air-cooled units low ambient
damper installed.
Factory Presets: Direct Acting
Possible Values: Direct Acting, Reverse Acting
