Active Outside Air Humidity
1. Press the NEXT key until the following screen is displayed. (if applicable)
Active Outside Air Humidity
ECEM Return Air Humidity
1. Press the NEXT key until the following screen is displayed.
VCM Outside Air Flow Input
1. Press the NEXT key until the following screen is displayed.
VCM CO Level Input
2
1. Press the NEXT key until the following screen is displayed.
WSM Water Flow Switch Input
1. Press the NEXT key until the following screen is displayed. (if applicable)
End of Submenu (NEXT) to Enter SETUP
1. Press the NEXT key until the following screen is displayed.
GBAS 0-5VDC Module Staus Submenu
Press ENTER to View Data in This Submenu
1. Press the NEXT key until the following screen is displayed.
GBAS (0-5VDC) Module Input 1 0.00 VDC
Assignment: Not Assigned
1. Press the NEXT key to display GBAS 0-5 VDC inputs 2, 3, and 4.
2. Press the NEXT key until the following screen is displayed.
GBAS (0-5VDC) Demand Limit Input Status
OPEN
1. Press the NEXT key until the following screen is displayed. (if applicable)
GBAS (0-5VDC) Module Relay Output Status
Output 1 OFF
End of Submenu (NEXT) to Enter SETUP
1. Press the NEXT key to leave the submenu and show following screen.
PKG-SVP01E-EN
30%
30%
62%
350.0 CCFM
1512 PPM
Flow
Programming Status
Used With: Units with an airside economizer only
Used With: Units with an airside economizer and
comparative enthalpy only.
Possible Values: 0-100%
Used With: Units with VCM.
Possible Values: 0 to max unit airflow
Used With: Units with VCM installed and CO
enabled.
Possible Values: 0-2000 PPM
Used With: Water-cooled units with a water flow
switch installed.
Possible Values: Flow, No Flow
Used With: Units with GBAS module
Used With: Units with GBAS module.
Possible Values: The inputs 1,2,3 and 4 may be
assigned to: Occ Zone Cooling Setpoint, Occ Zone
Heating Setpoint , Unocc Zone Cooling Setpoint,
Unocc Zone Heating Setpoint, Space Static Pressure
Setpoint, Supply Air Static Pressure Setpoint, Min O/
A Flow Setpoint, Not Assigned
Used With: Units with GBAS module.
Possible Values: Open, Closed
Used With: Units with GBAS module.
Possible Values: Open, Closed
reset
