Trane IntelliPak Signature Series Programming Manual page 15

Active Min OA Flow Setpoint
OA Flow 350.0 CCFM
1. Press the NEXT key until the following screen is displayed. (If applicable)
Active Min OA Flow Setpoint
CO Level 1512 PPM
2
1. Press the NEXT key until the following screen is displayed. (If applicable)
OA Preheat Output Control
1. Press the NEXT key until the following screen is displayed. (If applicable)
End of Submenu (NEXT) to Enter SETUP
1. Press the NEXT key to leave the submenu and show following screen.
2. Press PREVIOUS to page back through the submenu.
Compressor Status Submenu
Press ENTER to View Data in This Submenu
1. Pressing the NEXT key will display the following screen.
Compressor Relay K11
Enabled
1. Pressing the NEXT key will scroll forward through the screens.
Compressor Relay K12
Enabled
Note: On models SCWF/SIWF and SCRF/SIRF units, K12 is the "B" compressor on units with manifolded refrigerant
circuits and "C" compressor on all units with independent refrigerant circuits. Check unit model number, digit 5
to determine which type circuit the unit has.
1. Pressing the NEXT key will scroll forward through the screens.
Compressor Relay K3
Enabled
Note: On models SCWF/SIWF , 35-80 tons, K3 is the "B" compressor.
1. Pressing the NEXT key will scroll forward through the screens.
Compressor Relay K4
Enabled
1. Pressing the NEXT key will scroll forward through the screens.
Active Outside Air Temperature
Low Ambient Comp Lockout Temp:
1. Pressing the NEXT key will scroll forward through the screens.
PKG-SVP01E-EN
342.0 CCFM
OA Damper Pos 0%
342.0 CCFM
OA Damper Pos 0%
ON
OFF
OFF
OFF
OFF
86.0 F
32 F
Programming Status
Used With: All units VCM module and CO
enabled
Possible Values: Unit Airflow = 0 to maximum unit
airflow
Used With: All units VCM module or Traq™ damper
option only
Possible Values: Unit Airflow = 0 to maximum unit
airflow
Used With: All units VCM module and preheat
enabled
Possible Values: Unit Airflow = 0 to maximum unit
airflow
Possible Values: K11: ON, OFF, LOCKED, Disabled,
Enabled
Disabled by: Compressor protection, Frost
protection, contactor failure, Tracer Summit®
lockout, low pressure cutout, minimum off time, bad
cond temp sensor, low ambient lockout, demand
limit, ventilation override, low ent cond water temp.
Used With: Units with manifolded refrigerant circuits
Possible Values: K11: ON, OFF, LOCKED, Disabled,
Enabled
Used With: Units with independent refrigerant
circuits.
Possible Values: K3 = ON, OFF, LOCKED, Enabled,
Disabled
Used With: On model SCWF/SCIF, 60-80 tons units
Possible Values: K4 = ON, OFF, LOCKED, Disabled,
Enabled
Disabled by: Compressor protection, Frost
protection, contactor failure, Tracer Summit®
lockout, low pressure cutout, minimum off time, bad
cond temp sensor, low ambient lockout, demand
limit, ventilation override, low ent cond water temp.
Possible Lockout Values: Lockout Temperature =
-20 - 80 F
reset
