Active Outside Air Humidity
ECEM Return Air Humidity
1. Pressing the NEXT key will scroll forward through the screens.
End of Submenu (NEXT) to Enter SETUP
1. Pressing the NEXT key will scroll forward through the screens.
Controlling Setpoint Status Submenu
Press ENTER to View Data in This Submenu
1. Pressing the NEXT key will scroll forward through the screens.
Active Supply Air Cooling STP From
HI (KEY PAD) SETPOINT MENU
1. Pressing the NEXT key will scroll forward through the screens.
Active Supply Air Heating STP From
HI (KEY PAD) SETPOINT MENU
1. Pressing the NEXT key will scroll forward through the screens.
Active Daytime Warmup Setpoints
Initiate: 67 F is Terminate
1. Press the NEXT key until the following screen is displayed.
Active Occupied Zone Cooling STP From
RTM ZONE TEMP INPUT
1. Pressing the NEXT key will scroll forward through the screens.
Active Occupied Zone Cooling STP From
RTM ZONE TEMP INPUT is
1. Pressing the NEXT key will scroll forward through the screens.
Active Unoccupied Zone Cooling STP From
RTM ZONE TEMP INPUT is
1. Pressing the NEXT key will scroll forward through the screens.
Active Unoccupied Zone Heating STP From
RTM ZONE TEMP INPUT is
1. Pressing the NEXT key will bypass this section.
Active Morning Warmup Setpoint From
HI (KEYPAD) SETPOINT MENU is
1. Pressing the NEXT key will scroll forward through the screens.
PKG-SVP01E-EN
30%
62%
Is 55 F
Is 100 F
71 F
is 74 F
100 F
85 F
60 F
72 F
Programming Status
Used With: Units with an airside economizer only.
Possible Values: 0-100%
Used With: All VAV units only.
Possible Values: HI (Keypad) Setpoint Menu, Zone
Sensor Setpoint Input, GBAS 0-5 VDC Module, ICS
(Tracer Summit™)
Used With: All VAV units only.
Possible Values: HI (Keypad) Setpoint Menu, Zone
Sensor Setpoint Input, GBAS 0-5 VDC Module, ICS
(Tracer Summit™)
Used With: Units with hydronic, electric, or external
heat only.
Possible Values: HI (Keypad) Setpoint Menu
Possible Values: HI (Keypad) Setpoint Menu, Zone
Sensor Setpoint Input, NSB Zone Sensor Setpoint
Input, GBAS 0-5 VDC Module, ICS (Tracer Summit™)
Used With:Units with hydronic, electric, or external
heat with daytime warmup enabled only).
Possible Values: HI (Keypad) Setpoint Menu, Zone
Sensor Setpoint Input, NSB Zone Sensor Setpoint
Input, GBAS 0-5 VDC Module, ICS (Tracer Summit™)
Possible Values: HI (Keypad) Setpoint Menu, Zone
Sensor Setpoint Input, NSB Zone Sensor Setpoint
Input, GBAS 0-5 VDC Module, ICS (Tracer Summit™)
Used With:Units with hydronic, electric, or external
heat.
Possible Values: HI (Keypad) Setpoint Menu, Zone
Sensor Setpoint Input, NSB Zone Sensor Setpoint
Input, GBAS 0-5 VDC Module, ICS (Tracer Summit™)
Setpoint Range: 50-90 F
Used With:Units with hydronic, electric, or external
heat only.
Possible Values: HI (Keypad) Setpoint Menu, Zone
Sensor Setpoint Input, NSB Zone Sensor Setpoint
Input, GBAS 0-5 VDC Module, ICS (Tracer Summit™)
Setpoint Range: 50-90 F
