Trane IntelliPak Signature Series Programming Manual page 19

Active OA Temperature Sensor Input From
RTM OUTSIDE AIR TEMP INPUT
1. Pressing the NEXT key will scroll forward through the screens.
Active Outside Air Humidity Sensor Input From
OA HUMIDITY SENSOR INPUT
1. Pressing the NEXT key will scroll forward through the screens.
Active Supply Air Press Sensor Input From
RTM SA PRESSURE INPUT is
1. Pressing the NEXT key will scroll forward through the screens.
Temp Sensor Input Being Monitored
RTM ZONE TEMP INPUT is
1. Pressing the NEXT key will scroll forward through the screens.
End of Submenu (NEXT) to Enter SETUP
1. Press the NEXT key until the following screen is displayed. (if applicable)
Temperature Input Status Submenu
Press ENTER to View Data in This Submenu
1. Pressing the NEXT key will scroll forward through the screens.
Temp Meausured By Sensor Connected To
RTM ZONE TEMP INPUT
1. Press the NEXT key until the following screen is displayed. (if applicable)
Temp Meausured By Sensor Connected To
RTM SUPPLY AIR TEMP INPUT
1. Press the NEXT key until the following screen is displayed. (if applicable)
Temp Measured By Sensor Connected To
NSB Panel Temp Sensor Input
1. Press the NEXT key until the following screen is displayed. (if applicable)
Temp Measured By Sensor Connected To
RTM AUX TEMP INPUT
1. Press the NEXT key until the following screen is displayed.
Temp Measured By Sensor Connected To
RTM OUTSIDE AIR TEMP INPUT
1. Press the NEXT key until the following screen is displayed.
Temp Measured By Sensor Connected To
HEAT MODULE AUX TEMP INPUT
1. Press the NEXT key until the following screen is displayed. (if applicable)
Temp Measured By Sensor Connected To
ECEM RETURN AIR TEMP INPUT
1. Press the NEXT key until the following screen is displayed.
PKG-SVP01E-EN
is 86.0 F
Is 30%
2.1 IWC
82.0 F
82.0 F
50.0 F
79.5 F
62.0 F
86.0 F
82.0 F
78.0 F
Programming Status
Possible Values: RTM Outside Air Temp Input, ICS
(Tracer Summit™)
Used With: Units with an airside economizer.
Possible Values: O/A Humidity Sensor Input, ICS
(Tracer Summit™)
Sensor Range: 0 - 100%
Used With: Units with IGV, VFD or with the SAP
sensor enabled
Possible Values: RTM SA PRessure Input, ICS
(Tracer Summit™)
Possible Values: RTM Zone Temp Input, NSB Zone
Sensor Setpoint Input, RTM Aux Temp Input, ECEM
return Air Temp Input, ICS (Tracer Summit™)
Sensor Range: -40 to 200 F
Used With: Units with NSB zone sensor installed.
Used With: Units with hydronic, electric, or
external heat only
Used With: Units with a VCM and OA preheater
enabled.
19
