Installation Guide
Barometric Relief Damper
Packaged Rooftop Units
12.5 to 25 Tons
Model Number:
Used With:
BAYBARO300*
E/GBC180-300
FIABARM003*
T/YS*180-300
W/D/G*150-300
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment
can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or
serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are attached to the equipment.
August 2022
SAFETY WARNING
ACC-SVN156E-EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAYBARO300 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Trane BAYBARO300 Series

  • Page 1 Installation Guide Barometric Relief Damper Packaged Rooftop Units 12.5 to 25 Tons Model Number: Used With: BAYBARO300* E/GBC180-300 FIABARM003* T/YS*180-300 W/D/G*150-300 SAFETY WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
