PerkinElmer Lambda 365 Peltier Temp Ctrl Unit Multi Installation Instructions Manual page 34

3. The Functions of the Multi-Cell Calibration are shown as follows.
Command
MultiCell Position
Multicell Move
Multicell Calibration
Stop
Save Result
Reset Multicell
Although eight positions (steps) are displayed, only the first six (6) positions are used for 6-Position
NOTE:
Peltier Controlled Cell Changer. The last two positions remain 0 steps.
4. Click Reset Multicell to format the Multi-Cell steps. Click OK.
5. Click MultiCell Calibration. Then the following dialog box will appear. Remove all samples from the
6-Position Peltier Controlled Cell Changer. [Empty the 6-Position Peltier Controlled Cell Changer].
Click OK.
It shows saved steps of each cell position of the Multi-Cell.
It is used for moving Multi-Cell position as clicking buttons
.
It is used for moving Multi-Cell position using
by entered step.
Perform the Multi-Cell calibration.
Stop operation during Multi-Cell calibration.
It is used to save the calibrated result.
Move to '0' step of Multi-Cell position.
34
09931463A
Function
buttons
