Check the communication between Computer and Peltier Temperature Controller 201, see section
NOTE:
Setting USB Serial Port (page19) if the Method Setup is not activated.
9. The Peltier window will be shown. Select the Multi Cell Peltier tab and set parameters according to
the experiment conditions.
▶Multi-Cell holder
a. Available Cells: Indicate cells that are available for measurement. In the case of 6-Position
Peltier Controlled Cell Changer, six cells are available.
b. Using Cells: Show the cell positions which are selected for measurement. Remove the cells by
and switch positions by
c. Multi Zero, Multi Baseline: If checked, zero (baseline) will be measured all the selected
positions. If not, zero (baseline) will be only measured at the 1
cells. Multi Baseline is only available at the Scan and Scanning Kinetics mode.
To prevent inadequate baseline (zero) measurement because of the difference in transmittance among
NOTE:
cuvettes or any other reasons, Multi Baseline (Multi Zero) measurement is recommended.
d. Temperature (°C): Enter the returning temperature for the experiment.
e. Monitor: Select temperature that used to monitor during measurement. Options include: Block,
Probe1 or Probe2.
f. Error Range (°C/min): It shows the temperature tolerance between the sampling and
monitored temperature. The measurement will start when the temperature tolerance reaches
within the set Error Range.
Example: Set the starting temperature at 20°C and error range with 1°C then, the measurement
will start when the temperature is reached between 19°C and 21°C.
and keys.
30
09931463A
st
cell position among the using
