Overview SL6+
Voice Unit
If the default address settings
needs to be changed it
can be done in the main unit
using SafeLine Pro
Default address setting:
Address
Unit
1
Car unit
2
Top unit
3
Lift pit unit
4
Fire unit
5
Fire unit
6
Fire unit
Installation
1.
Local button*
Only N/O.
Is connected with *Cable13.
2.
Screw connector terminals*
3.
Emergency light*
Is connected with *Cable13.
4.
Hearing loop*
Is connected with *Cable13.
* Note: This connection
may not be present
depending on the nature
of your product.
1
2
ADDRESS
RS2
J2
8
5.
RS232 PC connection
For fi rmware update.
6.
Terminal RJ45
Input/output, bus connec-
tion, power and external
pictogram.
7.
Address selector
Selects the bus address for
the unit.
8.
Volume control
9.
Pictogram yellow
10.
Microphone
11.
Pictogram green
3
4
5
J4
J3
K1
K2
K3
K4
K5
K6
K7
K8
K9
K10
P6
P4
P5
P7
P2
P3
8
6
7
9
10
11
