Safeline SL3000 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SL3000
Manual
Lift emergency telephone
www.safeline-group.com
11.2019
SL3000 v.5.01 EN
Complies to EN81–28 and EN81–70 standards.
© 2019 SafeLine and all the SafeLine products and
accessories are copyrighted by law.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Safeline SL3000

Summary of Contents for Safeline SL3000

  • Page 1 SL3000 Manual Lift emergency telephone Complies to EN81–28 and EN81–70 standards. www.safeline-group.com © 2019 SafeLine and all the SafeLine products and 11.2019 accessories are copyrighted by law. SL3000 v.5.01 EN...

  • Page 2: Table Of Contents

    Technical Data General information Installation Component list Wiring diagram - Cable type 1 Wiring diagram - Cable type 2 Wiring diagram, SafeLine 3000 on a PSTN LINE Configuration Activating the SIM card Mounting Programming interfaces Programming method Programming Unit numbers...

  • Page 3: Technical Data

    10-30 Volts; 5 mA. Optically isolated. Relay outputs: Max 2A/30V DC, 0,5A/125V AC potential free relay outputs. Pictogram outputs: Max 100mA, 12 VDC. Transistor outputs. Open collector. Size: 205 x 160 x 45 mm (L x W x H). Weight: 1,5 kg. SL3000 v.5.01 EN...

  • Page 4: General Information

    - This quality product is dedicated for the lift industry. It has been designed and manufactured to be used for its specifi ed purpose only. If it is to be used for any other purpose, SafeLine must be contacted in advance.

  • Page 5: Installation

    The recorded message can be different for each unit. 6. Jumper for relay Selects NO/NC for the relays. 7. Jumper for emergency button Selects NO/NC for the emergency button. 8. Connector terminals: a, b, c, d and e 9. Volume control For loudspeaker in car. Turn right to increase the volume. 10. 12V Battery 11. Slot for PSTN or GSM card SL3000 v.5.01 EN...
  • Page 6 Component list SMA M 3000 PSTN card GSM card Extra station card Antenna 1&2. Terminal or RJ12 connector for PSTN line. Connect telephone line here. 3. GSM antenna connection, SMA 4. SIM-card holder 5. Volume controls For the extra remotes. Turn right to increase the volume. 6. Terminals For the extra voice stations. 7. GSM antenna SL3000 v.5.01 EN...

  • Page 7: Wiring Diagram - Cable Type

    + 12 V + 12 V AT Alarm + 12 V AT Alarm + 12 V AT Alarm + 12 V AT Alarm Em. button Acoustic NO / NC signal Blue Blue Brown Brown Yellow Yellow Green Green 230 VAC Yellow/Green Yellow/Green SL3000 v.5.01 EN...
  • Page 8 Orange Orange Black Black + 12 V + 12 V Emergency light Green + Yellow (+12V) Green + Yellow (+12V) Brown + Blue Brown + Blue Relay 1 Rel1 Rel2 Relay 2 For more information see parameter list code 88. SL3000 v.5.01 EN...

  • Page 9: Wiring Diagram - Cable Type 2

    + 12 V + 12 V at alarm + 12 V at alarm + 12 V at alarm + 12 V at alarm Em. button Acoustic NO / NC signal Brown Brown Brown/White Brown/White Green Green Blue/White Blue/White 230 VAC Yellow/Green Yellow/Green SL3000 v.5.01 EN...
  • Page 10 Blue - + 12 V + 12 V Emergency light Green + Blue/ Green + Blue/ White (+12V) White (+12V) Brown/White Brown/White + Brown + Brown Relay 1 Rel1 Rel2 Relay 2 For more information see parameter list code 88. SL3000 v.5.01 EN...

  • Page 11: Wiring Diagram, Safeline 3000 On A Pstn Line

    Wiring diagram, Connecting the phone line SafeLine 3000 on a PSTN LINE Phone Line out (Max 9 units) to next safeline Phone line in Phone line with RJ12 Parallel wiring Telephone line in Daisy-chain-wiring (Serial wiring) Telephone line in SL3000 v.5.01 EN...

  • Page 12: Configuration

    3. Make a call from your phone to verify that the SIM card is active, before you move it to the SafeLine 3000. 4. Also make a call to SafeLine 3000 after insertion to check that it is possible to get a proper connection.

  • Page 13: Mounting

    Unplug the main power and battery before performing any changes. To avoid GSM interference: Place the main unit, the stations and the GSM antenna more than 1.5 meters apart. SafeLine SL3000 SL6+ >>1.5 m >>1.5 m 0,1m ² >>1.5 Mounting PSTN board/GSM board Adding an extra station board. SL3000 v.5.01 EN...

  • Page 14: Programming Interfaces

    SL3000 1 2 3 4 5 6 7 8 9 Remote programming with SafeLine Pro. Connect an SLPro Link to a computer with SafeLine Pro and a serial cable. SafeLinePro SL3000 SL ProLink CONNECT app To configure the unit through the SafeLine CONNECT app, the CONNECTable (*CONNECTABLE) is required.

  • Page 15: Programming Method

    Enter setting, eg: 012341234 *00*# End parameter: # 2 short beeps 2 short beeps? Call disconnected or end of programming SL will restart with the new settings One long beep. Invalid input. Last code has to be reentered. SL3000 v.5.01 EN...

  • Page 16: Programming Unit Numbers

    Program unit as number 1 *82*n# Terminate programming Hang up *00*# Re-dial the phone number Press the next unit number repeatedly until hearing 3 beeps The next unit answers Program unit as number [1-9] Hang up Programming? Unit programming is done SL3000 v.5.01 EN...

  • Page 17: Configuration Examples - Safeline Autodialer Units

    6. Test alarm: (For P100 use telephone number of SLCC, for Caller ID set *31*4# and telephone number of GSM modem) 7. End configuration: If at any time you need to start over, use the factory reset command *99*1# SL3000 v.5.01 EN...

  • Page 18: Parameter List

    00-99 days. Always two digits. Max 3 days according to EN 81-28. 00 = No test alarms Test alarm protocol *31* Protocol test alarm 0 = P100 3 = CPC 4 = Phone number used as ID. SL3000 v.5.01 EN...
  • Page 19 1 = Enables recorded message. *63* # Play the the recorded message. Options for the recorded *64* 0 = Disable recorded message. message from lift pit 1 = Enables recorded message. *64* # Play the the recorded message. SL3000 v.5.01 EN...
  • Page 20 Detect dial tone *83* 0 = Off 1 = On (Default) Set to off if SafeLine has problem to detect the dial tone. Receipt to alarm receiver *84* Select which message(s) to send to the alarm receiver at an alarm call.
  • Page 21 Triggers an alarm event after programming is terminated. alarm event 1 = Emergency call 2 = Test alarm 3 = Battery failure 4 = Microphone/Loudspeaker failure 5 = Emergency call 6 = Maintenance 7 = Main unit power failure SL3000 v.5.01 EN...
  • Page 22 Go back to automatic mode press ”4”. The call is terminated by pressing ”#”. It is possible to enter manual voice switching mode although the unit is programmed as automatic by pressing ”*”. No ascending tones will be heard. SL3000 v.5.01 EN...

  • Page 23: Operation

    GSM-network. Audio self test failed. Flashing green - Telephone line connected. GSM-network OK. Flashing yellow - Incoming call. Flashing green - Call connection in progress. Continuous green - Call connected. Reset button Hold for 4 sec - Show GSM signal strength. Press 3 times - Start a battery service test Press once - Reset active alarm. SL3000 v.5.01 EN...

  • Page 24: Led Indication In Car

    The Green pictogram LED The Yellow Pictogram LED, is turns on as soon as the lit as soon as the alarm button SafeLine unit detects a respon- is pressed longer than the set ding voice. The LED is turned delay.

  • Page 25: Testing

    No reaction if valid telephone line connected. Check PSTN Connect a telephone to wiring or GSM the RJ12 connector on the front of the SafeLine 3000 Lift the handset No tone Internal dial tone Check the handset Press Phone line...

  • Page 26: Calling With Safeline 3000

    Emergency calls to numbers at the press of the alarm button. Test alarms at preset intervals. Send receipts to SLCC alarm receiver for defined conditions. Send SMS to one or several GSM phones at defined conditions (GSM only). Provoke test calls. Intercom between machine room and car/pit/car-top. SL3000 v.5.01 EN...

  • Page 27: Intercom Between Machine Room & Car/Pit/Top Of Car

    Press 3 to call the lift pit. 4 5 6 7 8 9 4 5 6 4 5 6 7 8 9 7 8 9 4 5 6 7 8 9 Press 00 to enter programming mode. SL3000 v.5.01 EN...

  • Page 28: Emergency Calling Process

    Emergency alarm activated Wait 1 minute Dial tone Line missing or busy Calling 1st phone number Answer Calling 2nd phone number Answer Calling 3rd phone number Answer Calling 4th phone number Answer Alarm operator made connection SL3000 v.5.01 EN...

  • Page 29: Service

    Mains power failure alarm is sent to the alarm receiver (SLCC) after 15 minutes of mains power failure. Testing the battery alarm: Unplug the battery terminal during the battery status check. The SafeLine 3000 will now emit a battery alarm and LED 2 and battery alarm relay will be activated(if so programmed). Changing the battery: •...

  • Page 30: Troubleshooting

    The unit can not make an alarm call. At least one phone number (and one ID code if using data identification) must be programmed to enable making a call from the unit. Refer to the parameter list (*11*). SL3000 v.5.01 EN...

  • Page 31: Declaration Of Conformity

    EU Declaration of Conformity Product: Lift telephone: SafeLine 3000 Type / model: SL 3000 Article no: *SL3000, *SL3000 GSM, *SL3000_GSM, *SL3000_LINEB, *SL3000_MAIN, *SL3000_MAINB, *SL3000_MINI, *SL3000_MINI GSM,*SL3000_MINIMAIN Incl. voice stations: *SL3000_REMMITSU, *SL3000_XREMB, *SL3000-XREMOTE*SLREM_COP, *SLREM_COP2, *SLREM_G, *SLREM_V2, *SLREM_V2-KIT, *SLREM_V2LED, *SLREM_V2-PIC, *SLREM_V2PICB, *SLREM_V3, *SLREM_V3LED,...
