Fire Mode

Operating
The SL6+ system can be used as a fi refi ghter intercom system.
Depending on the confi guration, you can have up to 6 voice
units as fi re units.
Fire mode is started by activating an input on the main unit.
Refer to the "Wiring Diagram SL6+ Main Unit" (page 12).
Confi guration
Use SafeLine Pro or parameter *73* (please refer to the corre-
sponding code in the "Parameter List") to confi gure the units
for Fire mode.
• Set Input 1 to Fire mode: *73*14#.
• Set Input 2 to Fire mode: *73*24# - default.
• Select other voice units to be included in Fire mode with SL
Pro.
Operation
Activating Fire mode does the following:
A siren sound is heard in the speaker of the main unit during the
active time.
Press the reset button to stop the siren sound.
A voice message specifi cally for Fire mode is played. Refer to
the "Distress message"-section of the "Parameter List" table.
When Fire mode is activated the units operate as intercom
units only and can not make emergency calls.
Voice communication
• Voice station in the car: microphone and speaker are both
active.
• Other units: the alarm button has the "Push to talk/Release to
listen"-function.
• A short beep is heard when you press/release the button.
• When in Fire mode, you can use the confi guration handset to
participate in an intercom conversation
• The yellow pictogram lights up when Fire mode is activated.
• The green pictogram lights up when in speech mode and is out
when listening.
• End Fire mode by disabling the input (1 or 2) on the main unit
confi gured for Fire mode.
+12 VDC
INPUT 1 (confi gurable)
INPUT 2 (confi gurable)
38
1
2
3
D
