LED Indication
Front Panel
LED 1 indicates the power supply status
Continuous green
Flashing red (400/400 ms)
Continuous red
LED 2 indicates active alarm and battery condition
Light off
Rapidly fl ashing yellow
(200/200 ms)
Flashing red (400/400 ms)
Continuous red
LED 3 indicates the phone line's status
Flashing green (100/100 ms)
Flashing green (400/400 ms)
Slowly fl ashing green
(200/4600 ms)
Continuous green
Flashing yellow (100/100 ms)
Flashing red (400/400 ms)
Continuous red
Reset button
or 3 sec
Press f
Press 3 times
Press once
Press 5 sec - release
Reset
44553
1000
6E
44553
1000
6E
44553
1000
6E
Startup
Mains power supply OK
Battery operated, with power to the emergency light.
Battery operated, no power to the emergency light.
No active alarm/battery OK.
Active alarm not reset.
Battery check in progress.
Battery test failure/no battery connected.
Fire mode activated.
Call connection in progress.
Telephone line connected.
GSM network OK.
Call connected.
Incoming call.
No telephone line connected.
Searching for GSM network.
No SIM card (when using GSM).
Show GSM signal strength (see table below).
Start a self test (battery + bus initialization).
Resets an active alarm. Aborts calls in progress.
SL6+ turns off. NOTE! Refers to battery powered only!
LED 1
LED 2
LED 3
16
COLOUR CODE
3 green
1 yellow, 2 green
2 yellow, 1 green
3 yellow
SL6 R1.12
1 red, 2 yellow*
2 red, 1 yellow
3 red
*Minimum signal strength for using GSM interface.
LED
GSM SIGNAL
1 2 3
STRENGTH
= 100 %
= 85 %
= 70 %
= 55 %
= 30 %
= 15 %
= 0 %
EN SL6+ v.3.04
