SafeLine SL6+
Technical Data Main Unit
Power
Battery
Emergency light
Emergency signal
Inputs
Antenna connector
Size
Weight
Relay outputs
IP code
Soundfiles
Bluetooth
Operating temperature
Air humidity
Interface Boards
Technical Data Voice Unit
Power
Inputs
Pictogram outputs
IP code
Max cable length
Operating temperature
Air humidity
Introduction
Supply voltage: 230 VAC min: 6,4 W, max: 9,4 W
Battery voltage: 12 VDC lead battery
Capacity: 1,2 Ah
Charge: 13,65 VDC, max. 200 mA
Emergency light output: 12 VDC max 500 mA
Acoustic emergency signal output: 12 VDC max 200 mA
10-30 VDC, 5 mA, optically isolated
SMA (female)
SL6+: 241 x 160 x 47 mm (L x W x H)
SL6+ Mini: 244 x 113 x 52 mm (L x W x H)
1.7 kg
Max 1 A/30 VDC. volt free relay outputs.
IP20
16 sec/file
Bluetooth 4.0
BLE 2,4 GHz
+5 C° — +40 C°
30% — 90% RH
*SL6-GSM-BOARD:
- Micro SIM, 15 x 12 x 0,76 mm
- Supports 2G
- Requires SW 3.40 or later
*IF-BOARD-4G
- Micro SIM, 15 x 12 x 0,76 mm
- Supports 2G, 3G and 4G
- Requires SW 4.45 or later
Supply voltage: 12 VDC, current drain nominal 15 mA
10-30 VDC, 5 mA, optically isolated
Max 100 mA, 24 VDC, transistor outputs, open collector
COP: IP00
COP2, Surface- or flush mounted units: IP40
To reach safety level IP4X, suitable additional protection have to
be installed onsite.
0,22 mm2 cable: 100 m
0,75 mm2 cable: 250 m
+5 C° — +40 C°
30% — 90% RH
