Digi ConnectCore 6UL Hardware Reference Manual page 71

ConnectCore
LGA ConnectCore 6UL signal
pad 6UL pad name
D11 LGA_D11 NAND_READY#
D12 LGA_D12 -
D13 LGA_D13 LTE_PRI
D14 LGA_D14 LTE_SYNC
D15 LGA_D15 BT_WAKEUP_
SLAVE
D16 LGA_D16 BT_UART1_
CTS#
i.MX6UL pad name Multiplexing
ALT0: NAND_READY_B
NAND_READY_B
ALT1: USDHC1_DATA4
ALT2: QSPI_A_DATA00
ALT3: ECSPI3_SS0
ALT4: EIM_CS1_B
ALT5: GPIO4_IO12
ALT6:
ALT7:
ALT8: UART3_TX
-
-
-
-
ALT0: UART1_CTS_B
UART1_CTS_B
ALT1: ENET1_RX_CLK
ALT2: USDHC1_WP
ALT3: CSI_DATA04
ALT4: ENET2_1588_EVENT1_IN
ALT5: GPIO1_IO18
ALT6:
ALT7:
ALT8: USDHC2_WP
Power group Comments
NVCC_NAND 10K pull-up on
module
connected to
VCC_NAND
Leave this line
floating if you
want to use the
on-module NAND
- Reserved
VDDIO_GPIO1
VDDIO_GPIO1
VDDIO_GPIO1
NVCC_UART Signal only
available in non-
wireless variants.
