ConnectCore
LGA
ConnectCore
6UL signal
pad
6UL pad
name
V9
LGA_V9
LCD_DATA15
V10
LGA_V10
LCD_DATA18
V11
LGA_V11
GND
V12
LGA_V12
LCD_DATA20
i.MX6UL pad name
Multiplexing
ALT0: LCDIF_DATA15
LCD_DATA15
ALT1: SAI3_TX_DATA
ALT2:
ALT3: CSI_DATA23
ALT4: EIM_DATA07
ALT5: GPIO3_IO20
ALT6: SRC_BT_CFG15
ALT7:
ALT8: USDHC2_DATA5
ALT0: LCDIF_DATA18
LCD_DATA18
ALT1: PWM5_OUT
ALT2: CA7_MX6UL_EVENTO
ALT3: CSI_DATA10
ALT4: EIM_DATA10
ALT5: GPIO3_IO23
ALT6: SRC_BT_CFG26
ALT7:
ALT8: USDHC2_CMD
-
ALT0: LCDIF_DATA20
LCD_DATA20
ALT1: UART8_TX
ALT2: ECSPI1_SCLK
ALT3: CSI_DATA12
ALT4: EIM_DATA12
ALT5: GPIO3_IO25
ALT6: SRC_BT_CFG28
ALT7:
ALT8: USDHC2_DATA0
Power group
Comments
NVCC_LCD
100K pull-down
on module
NVCC_LCD
-
NVCC_LCD
