ConnectCore
LGA
ConnectCore
6UL signal
pad
6UL pad
name
Y20
LGA_Y20
LCD_DATA17
Y21
JTAG_TDO
LGA_ Y21
AA1
LGA_AA1
GND
AA2
CSI_DATA0
LGA_ AA2
i.MX6UL pad name
Multiplexing
ALT0: LCDIF_DATA17
LCD_DATA17
ALT1: UART7_RX
ALT2:
ALT3: CSI_DATA00
ALT4: EIM_DATA09
ALT5: GPIO3_IO22
ALT6: SRC_BT_CFG25
ALT7:
ALT8: USDHC2_DATA7
ALT0: SJC_TDO
JTAG_TDO
ALT1: GPT2_CAPTURE2
ALT2: SAI2_TX_SYNC
ALT3: CCM_CLKO2
ALT4: CCM_STOP
ALT5: GPIO1_IO12
ALT6: MQS_RIGHT
ALT7:
ALT8: EPIT2_OUT
-
ALT0: CSI_DATA02
CSI_DATA00
ALT1: USDHC2_DATA0
ALT2: SIM1_PORT1_RST_B
ALT3: ECSPI2_SCLK
ALT4: EIM_AD00
ALT5: GPIO4_IO21
ALT6: SRC_INT_BOOT
ALT7:
ALT8: UART5_TX
Power group
Comments
NVCC_LCD
NVCC_GPIO
-
NVCC_CSI
