Digi ConnectCore 6UL Hardware Reference Manual page 41

ConnectCore
Castellated ConnectCore 6UL signal
pad 6UL pad name
14 / R1 CPAD14 CSI_MCLK
15 / T1 CPAD15 CSI_PIXCLK
16 / U1 CPAD16 CSI_DATA1
i.MX6UL pad name Multiplexing
ALT0: CSI_MCLK
CSI_MCLK
ALT1: USDHC2_CD_B
ALT2: NAND_CE2_B
ALT3: I2C1_SDA
ALT4: EIM_CS0_B
ALT5: GPIO4_IO17
ALT6: SNVS_VIO_5_CTL
ALT7:
ALT8: UART6_TX
ALT0: CSI_PIXCLK
CSI_PIXCLK
ALT1: USDHC2_WP
ALT2: NAND_CE3_B
ALT3: I2C1_SCL
ALT4: EIM_OE
ALT5: GPIO4_IO18
ALT6: SNVS_HP_VIO_5
ALT7:
ALT8: UART6_RX
ALT0: CSI_DATA03
CSI_DATA01
ALT1: USDHC2_DATA1
ALT2: SIM1_PORT1_SVEN
ALT3: ECSPI2_SS0
ALT4: EIM_AD01
ALT5: GPIO4_IO22
ALT6: SAI1_MCLK
ALT7:
ALT8: UART5_RX
Power
group Comments
NVCC_
CSI
NVCC_
CSI
NVCC_
CSI
