Digi ConnectCore 6UL Hardware Reference Manual page 61
System-on-module solution
Hide thumbs
Also See for ConnectCore 6UL:
- Hardware design manuallines (16 pages) ,
- Hardware reference manual (43 pages)
Table of Contents
Advertisement
ConnectCore
LGA
ConnectCore
6UL signal
pad
6UL pad
name
A12
LCD_DATA2
LGA_ A12
A13
GND
LGA_ A13
A14
LCD_DATA5
LGA_ A14
A15
LCD_DATA7
LGA_ A15
i.MX6UL pad name
Multiplexing
ALT0: LCDIF_DATA02
LCD_DATA02
ALT1: PWM3_OUT
ALT2:
ALT3: ENET1_1588_EVENT3_IN
ALT4: I2C4_SDA
ALT5: GPIO3_IO07
ALT6: SRC_BT_CFG02
ALT7:
ALT8: SAI1_TX_BCLK
-
ALT0: LCDIF_DATA05
LCD_DATA05
ALT1: UART8_RTS_B
ALT2:
ALT3: ENET2_1588_EVENT2_OUT
ALT4: SPDIF_OUT
ALT5: GPIO3_IO10
ALT6: SRC_BT_CFG05
ALT7:
ALT8: ECSPI1_SS1
ALT0: LCDIF_DATA07
LCD_DATA07
ALT1: UART7_RTS_B
ALT2:
ALT3: ENET2_1588_EVENT3_OUT
ALT4: SPDIF_EXT_CLK
ALT5: GPIO3_IO12
ALT6: SRC_BT_CFG07
ALT7:
ALT8: ECSPI1_SS3
Power group
Comments
NVCC_LCD
-
NVCC_LCD
NVCC_LCD
