ConnectCore
9P 9215 and Wi-9P 9215
Hardware Reference
90000879_F
Release date: March 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ConnectCore 9P 9215 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digi ConnectCore 9P 9215

Summary of Contents for Digi ConnectCore 9P 9215

  • Page 1 ™ ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference 90000879_F Release date: March 2009...
  • Page 2 Digi provides this document “as is,” without warranty of any kind, either expressed or implied, including, but not limited to, the implied warranties of fitness or merchantability for a particular purpose. Digi may make improvements and/or changes in this manual or in the product(s) and/or the program(s) described in this manual at any time.

  • Page 3: Table Of Contents

    Contents ............... Customer support ................
  • Page 4 C h a p t e r 2 : A b o u t t h e D e v e l o p m e n t B o a r d ....39 What’s on the development board? ............39 The development board ..............40 User interface ................41 General information ..............41 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 5 Antenna switch ................41 Switches and pushbuttons ............42 Reset control, S3 ................42 Power switch, S2 ................42 User pushbuttons, S6 and S7 ..............43 Legend for multi-pin switches .............. 43 Module configuration switches, S4 ............43 Wake-up button, S8 ................43 Serial Port B MEI configuration switches, S1 ..........
  • Page 6 Peripheral (expansion) headers ............63 Peripheral application header, X33 ............63 Module and test connectors ............64 Module connectors ................65 Test connectors ................65 X10 pinout ..................66 X11 pinout ..................66 X20 pinout ..................67 X21 pinout ..................68 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 7 IEEE802.11 a/b/g WLAN .............. 74 Typical module current / power measurements ......... 75 Typical power save current / power measurements ......75 ConnectCore 9P 9215 Module ............77 Top view ..................77 Module, side view ................77 ConnectCore Wi-9P 9215 Module ............ 79 Module, top view ................
  • Page 8 Radiation pattern: E-plane (2.0 and 5.0 GHz) ..........89 Appendix B:Certifications ..............91 FCC Part 15 Class B ..............91 Appendix C:Change log ..............97 Revision B ................97 Revision C ................97 Revision D ................97 Revision E ................98 Revision F ................98 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 9: Customer Support

    This guide provides information about the Digi ConnectCore 9P 9215 embedded core module. This table describes the typographic conventions used in this guide: Conventions used in this guide This convention Is used for italic type Emphasis, new terms, variables, and document titles.
  • Page 10 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 11 16 MB of NOR flash, up to 32 MB SDRAM, a rich set of integrated peripherals, and superior design flexibility. At the heart of the modules is a Digi 32-bit ARM9-based NS9215 processor running at 150 MHz. Key features include 10/100 Mbit Ethernet, two on-chip Flexible Interface Modules (FIMs), 256-bit AES accelerator, power management modes with dynamic clock scaling, and a rich set of on-chip peripherals.

  • Page 12: Features And Functionality

    NS9215 processor 2 LEDs (LE1: green, and LE2:orange) available on module 16-bit data and 17-bit address buses, both are buffered Single +3.3V power supply The ConnectCore 9P 9215 module is currently available in standard variants below. Module variant Product numbers: Features...

  • Page 13: Module Pinout

    M o d u l e p i n o u t ................. . The module has two 80 pins connectors, X1 and X2.
  • Page 14 WLAN signal. This signal comes directly from the Piper chip without series resistor. Buffered Data - only active when either CS0# or CS2# is active NS9215 D[31:16] Buffered Address always active ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 15 X1 pin Type Module functionality Usage on Comments number Development board EXT_OE# EXT_OE# EXT_WE# EXT_WE# CSO# CSO# CS2# CS2# BLE# BLE# NS9215 BE2# BHE# BHE# NS9215 BE3# EXT_WAIT# EXT_WAIT# 10k pull-up on module BCLK BCLK Connected over a 22R resistor to NS9215 CLK_OUT1 pin ETH_TPIN ETH_TPIN...
  • Page 16 (USB_OTG_ID) (USB_OTG_ID) VRTC VRTC Backup Battery for RTC, for 3V cell. Can be left floating, if RTC backup not needed. VLIO VLIO Mobile: Power from Li-Ion Battery (2.5V-5.5V) Non-Mobile: connected to 3.3V ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 17: X2 Pinout

    X2 pinout Type Module functionality Usage on Comments X2 pin Development board number DCDA#/ DMA0_DONE/ PIC_0_GEN_IO[0] GPIO0/ SPI_EN (dup) CTSA#/ EIRQ0/ PIC_0_GEN_IO[1] GPIO1/ -reserved- DSRA#/ EIRQ1/ PIC_0_GEN_IO[2] GPIO2/ -reserved- RXDA/ DMA0_PDEN/ PIC_0_GEN_IO[3] GPIO3/ SPI_RX (dup) RIA#/ EIRQ2/ Timer6_in/ GPIO4 SPI_CLK (dup)/ RTSA#/ RS485CTLA EIRQ3/ Timer6_Out/...
  • Page 18 Output, RST_DONE. To avoid RST_DONE/ input/output conflicts, put a series GPIO12/ resistor on this signal if SPI_CLK (dup) necessary. RTSC#/ QDCQ/ Ext Timer Event Out Ch 9/ GPIO13/ SPI_CLKboot DTRC#/ TXCLKC DMA1_REQ/ PIC_0_CAN_RXD GPIO14/ SPI_TXDboot ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 19 Type Module functionality Usage on Comments X2 pin Development board number TXDC/ Timer9_In/ PIC_0_CAN_TXD GPIO15/ SPI_ENboot DCDB# (dup)/ PIC_0_BUS_1[8] PIC_1_BUS_1[8] GPIO51/ CTSB# (dup)/ PIC_0_BUS_1[9] PIC_1_BUS_1[9] GPIO52/ DSRB# (dup)/ PIC_0_BUS_1[10] PIC_1_BUS_1[10] GPIO53/ RXDB (dup)/ PIC_0_BUS_1[11] PIC_1_BUS_1[11] GPIO54/ RIB# (dup)/ PIC_0_BUS_1[12] PIC_1_BUS_1[12] GPIO55/ RTSB# (dup) / RS485CTLB (dup) / PIC_0_BUS_1[13]...
  • Page 20 RTSD# (dup) / RS485CTLD(dup) / PIC_0_BUS_1[21] PIC_1_BUS_1[21] GPIO64/ TXCLKD (dup) / DTRD# (dup) / PIC_0_BUS_1[22] PIC_1_BUS_1[22] GPIO65 TXDD (dup) / PIC_0_BUS_1[23] PIC_1_BUS_1[23] GPIO66 PIC_0_CLK[I] PIC_0_CLK[0] EIRQ3 (dup)/ GPIO67 PIC_0_GEN_IO[0] PIC_1_GEN_IO[0] PIC_1_CAN_RXD GPIO68 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 21 Type Module functionality Usage on Comments X2 pin Development board number PIC_0_GEN_IO[1] PIC_1_GEN_IO[1] PIC_1_CAN_TXD GPIO69 PIC_0_GEN_IO[2] PIC_1_GEN_IO[2] PWM0/ GPIO70 PIC_0_GEN_IO[3] PIC_1_GEN_IO[3] PWM1/ GPIO71 PIC_0_GEN_IO[4] PIC_1_GEN_IO[4] PWM2/ GPIO72 PIC_0_GEN_IO[5] PIC_1_GEN_IO[5] PWM3/ GPIO73 PIC_0_GEN_IO[6] PIC_1_GEN_IO[6] Timer0_In/ GPIO74 PIC_0_GEN_IO[7] PIC_1_GEN_IO[7] Timer1_In/ GPIO75 PIC_0_CTL_IO[0] PIC_1_CTL_IO[0] Timer2_In/ GPIO76...
  • Page 22 GPIO81 PIC_0_BUS_0[2] PIC_1_BUS_0[2] Timer8_In (dup)/ GPIO82 PIC_0_BUS_0[3] PIC_1_BUS_0[3] Timer9_In (dup)/ GPIO83 PIC_0_BUS_0[4] PIC_1_BUS_0[4] Timer0_Out/ GPIO84 PIC_0_BUS_0[5] PIC_1_BUS_0[5] Timer1_Out/ GPIO85 PIC_0_BUS_0[6] PIC_1_BUS_0[6] Timer2_Out/ GPIO86 PIC_0_BUS_0[7] PIC_1_BUS_0[7] Timer3_Out/ GPIO87 PIC_0_BUS_0[13]/ PIC_1_BUS_0[13]/ Timer9_Out (dup)/ GPIO93 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 23 Type Module functionality Usage on Comments X2 pin Development board number PIC_0_BUS_0[14]/ PIC_1_BUS_0[14]/ QDCI (dup)/ GPIO94 PIC_0_BUS_0[15]/ PIC_1_BUS_0[15]/ QDCQ (dup)/ GPIO95 PIC_0_BUS_1[0]/ PIC_1_BUS_1[0]/ PIC_0_CAN_RXD GPIO96 PIC_0_BUS_1[1]/ PIC_1_BUS_1[1]/ PIC_0_CAN_TXD GPIO97 PIC_0_BUS_1[2]/ PIC_1_BUS_1[2]/ PIC_1_CAN_RXD GPIO98 PIC_0_BUS_1[3]/ PIC_1_BUS_1[3]/ PIC_1_CAN_TXD GPIO99 PIC_0_BUS_1[4]/ PIC_1_BUS_1[4]/ PWM4/ GPIO100 PIC_0_BUS_1[5]/ PIC_1_BUS_1[5]/...
  • Page 24 X2 pin Development board number VIN0_ADC VIN1_ADC VIN2_ADC VIN3_ADC VIN4_ADC VIN5_ADC VIN6_ADC VIN7_ADC VSS_ADC Connected on module to AGND Ω through 0 resistor VREF_ADC 100nF decoupling capacitor between VREF_ADC and VSS_ADC 3.3V 3.3V ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 25: Configuration Pins — Cpu

    C o n f i g u r a t i o n p i n s — C P U ................. . None of the 64 GPIO pins on connector X2 disturb CPU boot strap functions.

  • Page 26: Configuration Pins — Module

    ................. . The ConnectCore 9P 9215 and Wi-9P 9215 support the following JTAG signals: TCK, TMS, TDI, TDO, TRST#, and RTCK.

  • Page 27: Clock Generation

    ................. . Hardware strapping determines the initial powerup PLL settings. The table below Clock frequencies summarizes the default clock frequencies for the ConnectCore 9P 9215 and Wi-9P 9215 modules: Hardware strapping: "PLL reference clock divider setting:...

  • Page 28: Changing The Cpu Speed

    ................. . The ConnectCore 9P 9215 and Wi-9P 9215 modules boot directly from NOR flash.

  • Page 29: Chip Selects

    C h i p s e l e c t s ................. . The module has eight chip selects: four for dynamic memory and four for static memory.

  • Page 30: Gpio Multiplex Table

    GPIO7 TXDA Timer8_In Timer7_Out SPI_TXD (dup) TXDA / SPI_TXD GPIO8 DCDC# / TXCLKC DMA1_DONE Timer8_Out SPI_EN# (dup) DCDC# GPIO9 CTSC# I2C_SCL EIRQ0 (dup) PIC_DBG_DATA_IN CTSC# GPIO10 DSRC# QDCI EIRQ1 (dup) PIC_DBG_CLK DSRC# ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 31 Port Alternate function Alternate function Alternate Alternate On module, default name, function 02 function 04 (only used as Function GPIO00...GPIO15) GPIO11 RXDC# DMA1_PDEN EIRQ2 (dup) SPI_RXD (boot) RXDC GPIO12 RXCLKC / RIC# I2C_SDA RESET_DONE SPI_CLK (dup) RIC# GPIO13 RXCLKC / RTSC# QDCQ Timer9_out SPI_CLK (boot)
  • Page 32 RTSB# / 485CTLB PIC_0_BUS_1[13] PIC_1_BUS_1[13] RTSB# (dup) GPIO57 TXCLKB (dup) / PIC_0_BUS_1[14] PIC_1_BUS_1[14] DTRB# DTRB# (dup) GPIO58 TXDB (dup) PIC_0_BUS_1[15] PIC_1_BUS_1[15] TXDB GPIO59 DCDD# (dup) PIC_0_BUS_1[16] PIC_1_BUS_1[16] DCDD# GPIO60 CTSD# (dup) PIC_0_BUS_1[17] PIC_1_BUS_1[17] CTSD# ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 33 Port Alternate function Alternate function Alternate Alternate On module, default name, function 02 function 04 (only used as Function GPIO00...GPIO15) GPIO61 DSRD# (dup) PIC_0_BUS_1[18] PIC_1_BUS_1[18] DSRD# GPIO62 RXDD (dup) PIC_0_BUS_1[19] PIC_1_BUS_1[19] RXDD GPIO63 RID# (dup) PIC_0_BUS_1[20] PIC_1_BUS_1[20] RID# GPIO64 RTSD# / 485CTLD PIC_0_BUS_1[21] PIC_1_BUS_1[21] RTSD#...

  • Page 34: Module Leds

    ConnectCore Wi-9P module: To indicate WLAN-related information, such as association status and network activity. ConnectCore 9Pand Wi-9Pmodules: LE1 will flash a repeating blink pattern in a major system failure; for example, a processor exception or Power on Self Test failure. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 35: Description

    Network traffic is received or transmitted Network is idle Note: The network activity LED is used for diagnostic purposes during boot-up. The ConnectCore 9P 9215 and Wi-9P 9215 modules provide access to four external External interrupts interrupts signals, which are multiplexed with other functions on the GPIO pins.

  • Page 36: Interfaces

    C bus is completely free on the module - no EEPROM and no RTC - since the RTC is in the processor. The I²C clock is max 400kHz. I2C signals are provided on the module with 4k7 pull-up resistors. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 37: Wlan

    300 MHz maximum core clock (4x NS9215 bus speed) with 192-byte data and 2 KB program SRAM. The FIMs allow the flexible software-based selection of Digi-provided application specific hardware interfaces such as UART, SD/SDIO, 1-Wire, CAN bus, and others.

  • Page 38: Antenna

    The internal 1.8V core voltage is generated through a high-efficiency synchronous Internal voltage step-down converter, which uses VLIO as input voltage. The core voltage regulator can provide up to 600mA. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 39: What's On The Development Board

    About the Development Board he ConnectCore 9P 9215 Development board supports the ConnectCore 9P 9215 and Wi-9P 9215 modules. This chapter describes the components of the development board and explains how to configure the board for your requirements. The development board has two 4x20 pin connectors that are 1:1 copies of the module pins.

  • Page 40: The Development Board

    Development board + module, and module alone – 3.3V coincell battery with socket – PoE connectors for optional application kit (IEEE 802.3af) – Prototyping area (15 x 28 holes) with +3.3V and GND connections The development board ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 41: User Interface

    ................. . The ConnectCore 9P 9215 Development board implements two user buttons and two user LEDs in addition to those provided on the module.

  • Page 42: Switches And Pushbuttons

    Power switch, S2 both 9V-30V input power supply and 12V coming out of the PoE module. However, if a power plug is connected in the DC power jack, the PoE module is disabled. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 43: User Pushbuttons, S6 And S7

    Use the user pushbuttons to interact with the applications running on the User pushbuttons, S6 and S7 ConnectCore 9P 9215 and Wi-9P 9215 modules. Use these module signals to implement the pushbuttons: Signal name Switch GPIO used (pushbutton) USER_PUSH_BUTTON_1 GPIO81...
  • Page 44 Down feature (S1.2 = ON) - be sure that no cable is connected to connector S1.3 On = 2-wire interface (RS422/RS485) Off = 4-wire interface (RS422) S1.4 On = Termination on Off = No termination ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 45: Jumpers

    J u m p e r s ................. . Battery Jumper J2 WLAN Jumper J3 Serial Port D...

  • Page 46: Battery And Battery Holder

    ................. . Battery Holder Battery Coin-Cell Holder for CR2477 Battery, Lithium coin cell, CR2477, 24mm, 950mAh Keystone 1025-7 Panasonic CR2477 Ettinger 15.61.252 Renata CR2477N ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 47: Leds

    L E D s ................. . Power LED 9-30V, LE3 Power LED +3.3V, LE4 WLAN LED LE7...

  • Page 48: Serial Status Leds

    Serial Port B LEDs LED reference Function GREEN LE64 LE49 DCDB#/GPIO51 LE65 LE50 RIB#/GPIO55 LE66 LE51 DSRB#/GPIO53 LE67 LE52 DTRB#/GPIO57 LE68 LE53 CTSB#/GPIO52 LE69 LE54 RTSB#/GPIO56 LE70 LE55 RXDB/GPIO54 LE71 LE56 TXDB/GPIO58 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 49: Serial Uart Ports

    S e r i a l U A R T p o r t s ................. . The development board supports the four serial ports available on the ConnectCore 9P 9215 and Wi-9P 9215 modules.

  • Page 50: Serial Port A Ttl Interface

    Serial Port A must not be connected if SPI or WakeUp functionality is used. The serial (UART) port C interface is a TTL interface connected to a 2x5 pin, 0.1” Serial port C TTL interface connector, X5. The connector supports only TTL level. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 51: Serial Port B, Mei Interface

    The serial port C interface corresponds to the NS9215 UART port C. The signals are shared with the HDLC interface. Serial port C pins are allocated as shown: Function Defaults to DCDC#/TXCLKC GPIO8. DSRC# GPIO10. RXDC# GPIO11 RTSC#/RXCLKC GPIO13 TXDC GPIO15 CTSC# GPIO9...

  • Page 52: I2C Header,

    ................. . I2C header, X15 I2C digital I/Os, X44 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 53 The I²C interface has only one device connected to the bus on the development C header board - an I/O expander (see next paragraph). Otherwise, additional I²C devices (like EEPROMs) can be connected to the module by using I²C header X15. The pinning of this header is provided below.

  • Page 54: Spi Interface

    Note: The default configuration of UART port A is to support GPIOs. To move from GPIO to UART or SPI, you need to configure the software properly. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 55: Pin Allocation

    ................. . The Current Measurement Option uses 0.025R ohm series resistors to measure the current. The ConnectCore 9P 9215 Development board allows to measure: the current used by the development board and module (through R80), and the current used by the internal NS9215 1.8V core generated from VLIO using a...
  • Page 56 (CMO) resistor. The value of the resistor is 0.025 ± 1%. Calculate the current using this equation: I = U/R where I = current in Amps U = measured voltage in Volts R = 0.025 Ohms ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 57: Jtag Interface

    ................. . JTAG Multi-Ice connector X13 The standard JTAG ARM connector is a 20-pin header and can be used to connect Standard JTAG ARM connector, development tools such as Digi’s JTAG Link, ARM’s Multi-ICE, Abatron BDI2000, and others. Signal Signal +3.3V +3.3V...

  • Page 58: Poe Module Connectors - Ieee802.3Af

    X9, input connector: Provides access to the signals coming from the Ethernet interface. X26, output connector: Provides the output power supply from the PoE module. Note: The PoE interface is only available for the ConnectCore 9P 9215 module. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 59: The Poe Module

    Power Jack, X24 PoE header, PoE header, Plug in the PoE module at a right angle to the development board, as shown in this The PoE module drawing: PoE module Jump Start development board www.digiembedded.com...

  • Page 60: Poe_Gnd

    The Ethernet connector is an 8-wire RJ-45 jack, labeled , on the development board. The connector has eight interface pins, as well as two integrated LEDs that provide link status and network activity information. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 61: Rj-45 Pin Allocation, X19

    Ethernet RJ-45, X19 RJ-45 connector pins are configured as shown: RJ-45 pin allocation, X19 Signal 802.3af End-Span (mode A) 802.3af Mid-Span (Mode B) Description TXD+ Negative V Transmit data + Port TXD- Negative V Transmit data - Port RXD+ Positive V Receive data + Port EPWR+...

  • Page 62: Leds

    For the ConnectCore Wi-9P 9215, attach the antenna to the primary connector [X17] and the secondary connector [X18] on the development board. See figure below. Secondary antenna connector [X18] Primary antenna connector [X17] ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 63: Peripheral (Expansion) Headers

    (such as CE#, IRQ#, WE#), as well as I C and power (+3.3V). Using these signals, you can connect Digi-specific extension modules or your own daughter card to the module’s address/data bus. Peripheral application pins are allocated as shown:...

  • Page 64: Module And Test Connectors

    ................. . The ConnectCore 9P 9215 and Wi-9P 9215 modules plug into the module connectors X1 and X2 on the development board.

  • Page 65: Module Connectors

    Test Connector, X10, X11 Module connector, Module connector, Test connector, X20, X21 See “Module pinout” on page 13 for related information. Module connectors The development board provides two 4x20 pin test connectors, labeled X10/X11 and Test connectors X20/X21. These connectors are 1:1 copies of the module pins and are used for measurement or test purposes.

  • Page 66: X10 Pinout

    Reserved* Reserved* VBAT *USB signals are reserved for future use. X11 pinout X11 pin Signal X11 pin Signal RSTIN# SRESET# RTCK OCD_EN# SW_CONF0 SW_CONF1 WLAN_LED# (CC Wi-9P 9215) BD10 BD11 BD14 BD15 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 67: X20 Pinout

    X11 pin Signal X11 pin Signal BA10 BA13 BA14 EXT_OE# EXT_CS2# BE2# EXT_CLK (ETH_TPIP) NC NC (ETH_LINK#) Reserved* Reserved* Reserved* 3.3V *USB signals are reserved for future use. X20 pinout X20 pin Signal X20 pin Signal DSRA#/GPIO2 RXDA/SPI_RXD/GPIO3 DTRA#/GPIO6 TXDA/SPI_TXD/GPIO7 DSRC#/GPIO10 RXDC/GPIO11 DTRC#/TXCLKC/GPIO14...

  • Page 68: X21 Pinout

    RIC#/RXCLKC/GPIO12 RTSC#/RCLKC/GPIO13 DCDB#/GPIO51 CTSB#/GPIO52 RIB#/GPIO55 RTSB#/GPIO56 DCDD#/GPIO59 CTSD#/GPIO60 RID#/GPIO63 RTSD#/GPIO64 GPIO67 GPIO68 GPIO71 GPIO72 GPIO75 GPIO76 GPIO79 GPIO80 GPIO83 USER_BUTTON2#/GPIO84 GPIO87 GPIO93 CAN0_RXD/GPIO96 CAN0_TXD/GPIO97 GPIO100 EIR03#/GPIO101 ADC_IN0 ADC_IN1 ADC_IN4 ADC_IN5 AGND_ADC VREF_ADC ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 69: Appendix A:specifications

    Appendix A:Specifications his appendix provides environmental, mechanical, safety and power information for the ConnectCore 9P 9215 and Wi-9P 9215 modules. M e c h a n i c a l i n f o r m a t i o n .

  • Page 70: Wlan

    ................. . The module board assemblies meet all functional requirements when operating in this environments provided below. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 71: Thermal Specifications

    ................. . The table below shows the specific standard operating temperature ranges for the entire ConnectCore 9P 9215 embedded core module family. Standard Operating Temperature Ranges...

  • Page 72: Additional Design Recommendations

    Providing air movement will improve heat dissipation. The host PCB plays a large part in dissipating the heat generated by the module. A large copper plane located will improve the heat dissipation capabilities of the PCB. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 73: Safety Statements

    If the design allows, added buried PCB planes will also improve heat dissipation. The copper planes create a larger surface to spread the heat into the surrounding environment. S a f e t y s t a t e m e n t s .

  • Page 74: Ieee802.11 A/B/G Wlan

    The WLAN baseband controller can be reset through GPIO92. When this signal is low, the baseband controller is in reset mode. When high, the controller is active. The interrupt signal connected to the baseband controller is GPIO_AO. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 75: Typical Module Current / Power Measurements

    ................. . The following illustrates typical power consumption for a ConnectCore 9P 9215 and...
  • Page 76 For the ConnectCore Wi-9P 9215, the clock scaling is divided by 4, for the ConnectCore 9P 9215, the clock scaling is divided by 16. This measurement was produced by selecting the "Deep Sleep/Wakeup with an External IRQ" menu option in the napsave sample application. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 77: Connectcore 9P 9215 Module

    C o n n e c t C o r e 9 P 9 2 1 5 M o d u l e ................. . Measurements are in millimeters.
  • Page 78 Device Berg/FCI connector ConnectCore 9P 9215 module 61082-081409LF ConnectCore 9P 9215 JumpStart board 61083-084409LF (mating connector on the base board) ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 79: Connectcore Wi-9P 9215 Module

    C o n n e c t C o r e W i - 9 P 9 2 1 5 M o d u l e ................. . Measurements are in millimeters.

  • Page 80: Layout Recommendation

    ................. . Below are the mechanical dimensions of the ConnectCore 9P 9215 module.
  • Page 81 61082-081409LF ConnectCore 9P 9215 JumpStart board 61083-084409LF (mating connector on the base board) Device Berg/FCI connector ConnectCore 9P 9215 - Wi-9P 9215 module 61082-081409LF ConnectCore Wi-9P 9215 JumpStart board 61083-084409LF (mating ConnectCore 9P 9215 - Wi-9P 9215 JumpStart board) www.digiembedded.com...
  • Page 82 C o n n e c t C o r e W i - 9P 92 15 Below are the mechanical dimensions of the ConnectCoreWi- 9P 9215 module. BOTTOM View. TOP View ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 83 SIDE view Device Berg/FCI connector ConnectCore Wi-9P 9215 61082-081409LF ConnectCore Wi-9P 9215 JumpStart board 61083-084409LF (mating ConnectCore 9P 9215 - Wi-9P 9215 JumpStart board) www.digiembedded.com...

  • Page 84: Reset And Edge Sensitive Input Timing Requirements

    = 0.8V to 2.0V negative edge input max = 500nsec = 2.0V to 0.8V On the ConnectCore 9P 9215 JumpStart there was a measurement of 220ns rise time and 10ns fall time. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 85: Antenna Specifications: 2 Dbi Dipole

    A n t e n n a s p e c i f i c a t i o n s : 2 d B i D i p o l e ................. . Attributes Attribute Property...
  • Page 86 The red solid line represents the horizontal plane and the green dotted line represents the vertical plane. You can see in the illustration that at 90 degrees, the signal strength is 0 (as expected). ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 87: Antenna Specifications: 5.5 Dbi Dipoles

    A n t e n n a s p e c i f i c a t i o n s : 5 . 5 d B i D i p o l e s ................. . Attributes Attributes Band 1...

  • Page 88: Dimensions

    Dimensions Note:Dimensions are provided for reference purposes only. The actual antenna might vary. Radiation pattern: H-Plane (2.0 and 5.0 GHz) Color Freq (MHz) Peak (dBi) Angle (o) Avg (dBi) ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 89: Radiation Pattern: E-Plane (2.0 And 5.0 Ghz)

    Yellow 2400.0 3.39 257.68 2.98 2450.00 3.17 214.74 2.37 Blue 2500.00 2.79 288.0 1.96 Purple 5150.00 2.25 280.42 0.82 Green 5200.00 5.23 252.63 2.71 Light brown 5250.00 4.51 272.84 3.16 Orange 5750.00 5.03 267.79 3.88 Aqua 5850.00 3.83 276.63 2.74 Radiation pattern: E-plane (2.0 and 5.0 GHz)
  • Page 90 -1.36 Blue 2500.00 1.92 237.27 -1.78 Purple 5150.00 2.37 78.67 -1.91 Green 5200.00 4.80 79.30 0.32 Light brown 5250.00 4.49 79.93 -0.01 Orange 5750.00 6.34 283.85 1.08 Aqua 5850.00 4.67 283.22 -0.46 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 91: Appendix B:certifications

    Appendix B:Certifications he ConnectCore 9P 9215 and Wi-9P 9215 products comply with the standards cited in this section. F C C P a r t 1 5 C l a s s B ................. .
  • Page 92 20 cm separation, and end users must be also be advised of the requirement. Modifications (FCC 15.21) Changes or modifications to this equipment not expressly approved by Digi may void the user’s authority to operate this equipment. Industry Canada...
  • Page 93 This limit is met with the highest gain antenna listed, World Products Inc WPANTE3. OEM installers and users are cautioned to take note that high-power radars are allocated as primary users (meaning they have priority) of the bands 5250-5350 MHz and 5650-5850 MHz and these radars could cause interference and/or damage to devices operating in these frequency bands.
  • Page 94 The product listed above has been tested at an External Test Laboratory certified per FCC rules and has been found to meet the FCC, Part 15, Class B, Emission Limits. Documentation is on file and available from the Digi International Homologation Department.
  • Page 95 International EMC Standards The ConnectCore 9P 9215 and the Wi-9P 9215 meets the following standards: Standards ConnectCore 9P 9215 Emissions FCC Part 15 Subpart B ICES-003 Immunity EN 55022 EN 55024 Safety UL 60950-1 CSA C22.2, No. 60950-1 EN60950-1 www.digiembedded.com...
  • Page 96 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...

  • Page 97: Appendix C:change Log

    ................. . On page 9 updated Digi Information.

  • Page 98: Revision E

    ................. . Minor data corrections were made and Canadian certifications information was expanded. ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
  • Page 99 P N ( 1 P ) : 9 0 0 0 0 8 7 9 - 8 8 F...
  • Page 100 ConnectCore 9P 9215 and Wi-9P 9215 Hardware Reference...
