Digi ConnectCore 6UL Hardware Reference Manual page 90

ConnectCore
LGA ConnectCore 6UL signal
pad 6UL pad name
V3 LGA_V3 BOOT_MODE0
V4 LGA_V4 GND
V5 LGA_V5 (VDD_SNVS)
GPIO5_02
V6 LGA_V6 GND
V7 LGA_V7 LCD_DATA10
V8 LGA_V8 LCD_DATA12
i.MX6UL pad name Multiplexing
BOOT_MODE0
-
ALT5: GPIO05_IO02
SNVS_TAMPER2
-
ALT0: LCDIF_DATA10
LCD_DATA10
ALT1: SAI3_RX_SYNC
ALT2:
ALT3: CSI_DATA18
ALT4: EIM_DATA02
ALT5: GPIO3_IO15
ALT6: SRC_BT_CFG10
ALT7:
ALT8: FLEXCAN2_TX
ALT0: LCDIF_DATA12
LCD_DATA12
ALT1: SAI3_TX_SYNC
ALT2:
ALT3: CSI_DATA20
ALT4: EIM_DATA04
ALT5: GPIO3_IO17
ALT6: SRC_BT_CFG12
ALT7:
ALT8: ECSPI1_RDY
Power group Comments
VDD_SNVS 100K pull-down
resistor
-
VDD_SNVS
-
NVCC_LCD 100K pull-down
on module
NVCC_LCD 100K pull-down
on module
