About the ConnectCore® 6UL
ARM TrustZone
o
CAAM (cryptographic acceleration and assurance module)
o
SNVS (secure non-volatile storage)
o
CSU (central security unit)
o
A-HABv4 (advanced high-assurance boot)
o
IEEE 802.11 a/b/g/n/ac WLAN interface
l
Bluetooth® version 4.2 dual-mode
l
ARM Cortex-M0+ Micro Controller Assist™ (MCA) subsystem
l
Debug interfaces:
l
System JTAG controller
o
Single Wired Debug (SWD) interface for the MCA
o
Support of i.MX6UL interfaces:
l
16-bit data/address bus
o
Display: 24-bit parallel bus
o
Camera: 24-bit parallel bus
o
KPP (key pad port)
o
TSC (touch screen controller)
o
x 2 MMC/SD/SDIO card ports
o
x 2 USB 2.0 OTG with integrated HS USB PHYs
o
x 2 10/100 Mbps Ethernet MAC
o
UART, SPI, I2C, PWM, ADC, CAN, I2S, and GPIOs
o
Ultra-miniature SMT module (29 x 29 x 3.5 mm) based on 245 pads (245 LGA, 76 also available as
l
castellated pads)

ConnectCore 6UL module variants

Smart
part Part
number number
CC-WMX- 50001939-
JN58-NE 01
ConnectCore® 6UL Hardware Reference Manual
ConnectCore
6UL SOM
variant Description
0x02 ConnectCore for
i.MX6UL, 528
MHz, Industrial
Temp, 256 MB
SLC NAND, 256
MB DDR3, Dual
10/100 Ethernet,
802.11a/b/g/n/ac,
Bluetooth 4.2,
ANT+
ConnectCore 6UL module variants
DDR3/Bus
1 2
WiFi/Bluetooth
CPU -width
G2CVK05 - 256MiB
40/+105°C (1x2Gbit)
528 MHz / 16bit, -
40/+95ºC
7
