Module specifications
mode of operation is supported by the ConnectCore 6UL module, the ConnectCore 6UL SBC Express
does not provide options to test/evaluate it.

Global power consumption

The following tables list the global power consumption of the ConnectCore 6UL module when the
system is under the use cases described below. See
specifications on the ConnectCore 6UL module variants listed below.
Suspend and power-off modes
Suspend to RAM mode
Front-end LDO
used (VSYS =
4.4V)
Variant 17.8 mW
0x02
Variant 17.204 mW
0x03
Variant 24 mW
0x04
Note In power-off mode, the input power supply of the SOM (VSYS-VSYS2) is not disconnected, so
VSNVS regulator is still powered. In RTC mode, only the MCA is powered. By cutting the input power
supply to the module in power-off mode, you can achieve the same power consumption numbers as in
RTC mode. See Power management
consumption in low-power modes.
Run-time modes
IDLE
Variant 0x02 0.442 W 0.460 W
Variant 0x03 0.306 W 0.328 W
Variant 0x04 0.477 W 0.500 W
Note These power consumption numbers should be considered guidelines only, never as fixed or
absolute values. Actual values will depend entirely upon individual setup and system application.
Power consumption: Wireless power consumption increase
The following tables shows the power consumption increase of the ConnectCore 6UL module when
transmitting in 2.4 GHz and 5 GHz modes:
ConnectCore® 6UL Hardware Reference Manual
Front-end LDO not
used (VSYS = 3.8V)
8.55 mW
8.094 mW
16.72 mW
for detailed information about how to optimize the power
Display connected (IDLE) Decoding video CPU stress
ConnectCore 6UL module variants
Power-off mode
Front-end LDO
used (VSYS = Front-end LDO not
4.4V) used (VSYS = 3.8V)
1.9 mW* 1.32 mW*
2.075 mW* 1.426 mW*
2.106 mW* 1.52 mW*
0.658 W 0.667 W
0.532 W 0.540 W
0.737 W 0.707 W
Power consumption
for
RTC
mode
7.5
uW*
